Drilling into the San Andreas fault zone has begun in central California as part of the U.S.G.S. program of fault zone studies. The purpose of drilling into the fault zone is threefold. First, it will allow recovery of material from depth in order to determine the composition of both solid and fluid phases. Second, it will allow determination of the physical state of the fault zone, that is, the state of stress, pore pressure, and temperature. Finally, it will allow emplacement of instruments at depth in the fault zone for monitoring experiments related to short-term earthquake prediction.
In an attempt to drill to the depth of earthquake focii, the initial drill site was chosen at a locale known as Dry Lake Valley (Fig. 1). Although the entire central section of the San Andreas fault is characterized by moderate seismicity and aseismic creep, Dry Lake Valley has particularly shallow earthquakes as well as a fairly high creep rate (18-20 mm/year). Figure 2 is a longitudinal section along the San Andreas fault. The high precision earthquake locations shown are magnitude one or greater events that occurred in 1973-1975 (from W. Ellsworth, pers. comm.). The depth estimates are accurate to about + 0.5 km. It is obvious from the figure that earthquakes in the section of the fault near the well are quite shallow.
