Near-field remote sensing of surface velocity and river discharge using radars and the probability concept at 10 USGS streamgages

April 20, 2020

Near-field remote sensing of surface velocity and river discharge (discharge) were measured using coherent, continuous wave Doppler and pulsed radars. Traditional streamgaging requires sensors be deployed in the water column; however, near-field remote sensing has the potential to transform streamgaging operations through non-contact methods in the U.S. Geological Survey (USGS) and other agencies around the world. To differentiate from satellite or high-altitude platforms, near-field remote sensing is conducted from fixed platforms such as bridges and cable stays. Radar gages were collocated with 10 USGS streamgages in river reaches of varying hydrologic and hydraulic characteristics, where basin size ranged from 381 to 66,200 square kilometers. Radar-derived mean-channel (mean) velocity and discharge were computed using the probability concept and were compared to conventional instantaneous measurements and time series. To test the efficacy of near-field methods, radars were deployed for extended periods of time to capture a range of hydraulic conditions and environmental factors. During the operational phase, continuous time series of surface velocity, radar-derived discharge, and stage-discharge were recorded, computed, and transmitted contemporaneously and continuously in real time every 5 to 15 min. Minimum and maximum surface velocities ranged from 0.30 to 3.84 m per second (m/s); minimum and maximum radar-derived discharges ranged from 0.17 to 4890 cubic meters per second (m3/s); and minimum and maximum stage-discharge ranged from 0.12 to 4950 m3/s. Comparisons between radar and stage-discharge time series were evaluated using goodness-of-fit statistics, which provided a measure of the utility of the probability concept to compute discharge from a singular surface velocity and cross-sectional area relative to conventional methods. Mean velocity and discharge data indicate that velocity radars are highly correlated with conventional methods and are a viable near-field remote sensing technology that can be operationalized to deliver real-time surface velocity, mean velocity, and discharge.

Publication Year 2020
Title Near-field remote sensing of surface velocity and river discharge using radars and the probability concept at 10 USGS streamgages
DOI 10.3390/rs12081296
Authors John Fulton, Chris A. Mason, Jack R. Eggleston, Matthew J. Nicotra, C.-L. Chiu, Mark F. Henneberg, Heather Best, Jay Cederberg, Stephen R. Holnbeck, R. Russell Lotspeich, Christopher Laveau, Tommaso Moramarco, Mark E. Jones, Jonathan J Gourley, Danny Wasielewski
Publication Type Article
Publication Subtype Journal Article
Series Title Remote Sensing
Index ID 70210892
Record Source USGS Publications Warehouse
USGS Organization Colorado Water Science Center
