Bathymetric Contour Maps for Lakes Surveyed in Iowa in 2006

December 2, 2008

The U.S. Geological Survey, in cooperation with the Iowa Department of Natural Resources, conducted bathymetric surveys on two lakes in Iowa during 2006 (Little Storm Lake and Silver Lake). The surveys were conducted to provide the Iowa Department of Natural Resources with information for the development of total maximum daily load limits, particularly for estimating sediment load and deposition rates. The bathymetric surveys can provide a baseline for future work on sediment loads and deposition rates for these lakes. Both of the lakes surveyed in 2006 are natural lakes.

For Silver Lake, bathymetric data were collected using boat-mounted, differential global positioning system, echo depth-sounding equipment, and computer software. For Little Storm Lake, because of its shallow nature, bathymetric data were collected using manual depth measurements. Data were processed with commercial hydrographic software and exported into a geographic information system for mapping and calculating area and volume. Lake volumes were estimated to be 7,547,000 cubic feet (173 acre-feet) at Little Storm Lake and 126,724,000 cubic feet (2,910 acre-feet) at Silver Lake. Surface areas were estimated to be 4,110,000 square feet (94 acres) at Little Storm Lake and 27,957,000 square feet (640 acres) at Silver Lake.

Citation Information

Publication Year 2008
Title Bathymetric Contour Maps for Lakes Surveyed in Iowa in 2006
DOI 10.3133/sim3051
Authors S.M. Linhart, K.D. Lund
Publication Type Report
Publication Subtype USGS Numbered Series
Series Title Scientific Investigations Map
Series Number 3051
Index ID sim3051
Record Source USGS Publications Warehouse
USGS Organization Iowa Water Science Center
