This geochemical map shows the distribution and abundance of molybdenum (Mo), copper (Cu), and lead (Pb) of -80 mesh (177 micrometers) stream sediment samples in the Chandalar quadrangle, Alaska. The map is a part of a series of geochemical maps that together with the background information circular (Reiser and others, 1978) comprise the folio on the Chandalar quadrangle, Alaska. The data are plotted on a subdued base map showing the generalized geology, topography, and sample localities. Map symbols showing the ranges of metal values are indicated on the accompanying histograms and all values shown are considered anomalous. An explanation of sampling, preparation, analytical procedures and geochemical raw data for all samples are discussed by O'Leary and others (1976). The -80 mesh (177 micrometers) stream sediment medium was used in this study because of the regional setting in the north-central Brooks Range. Given the rather restrictive time and manpower constraints the -80 mesh (177 micrometers) stream sediment combined with panned concentrates was determined to be the most economical and adequate medium in this case where clastic sediments are being derived from local bedrock.
The study area is generally one of high relief with short fast-moving streams and broad glacial valleys. All samples were taken from active streams, as close to the center channel as possible. All sediments were considered to be locally derived. Care was taken, when sampling an obviously glaciated terrane, to sample above or upstream from morainal material, wherever possible. Most samples were taken in areas where bedrock was within 30 m of the sample site.
