The purpose of this map is to aid in the mineral-resource assessment and exploration of covered host rocks by displaying and interpreting data that can be used to estimate the depth of basin fill in the Winnemucca 1° by 2° quadrangle, Nevada. Publicly available information used in making this map includes water, petroleum, and geothermal well data, gravity data and models, seismic profiles, and geologic and geomorphic reports.
Wells logs used for this map of the Winnemucca quadrangle are from the following sources: (1) logs of more than 1,000 water wells reported to the State of Nevada Division of Water Resources, which are on file with them in Reno and at the with U.S. Geological Survey in Carson City, (2) 44 petroleum wells collected by the Nevada Bureau of Mines (Lintz, 1957; Schilling and Garside, 1968; Garside and Schilling, 1977, Garside and others, 1977; 1988), and (3) Two geothermal wells reported in Zoback (1979) and Flynn and others (1982). Data from isostatic residual and Bouguer gravity maps by Wagini (1985) contributed to the interpretation of basin configuration. Gravity models of Dixie Valley (Schaefer, 1982, and Speed, 1976) and Grass Valley (Grannell and Noble, 1977) and seismic profiles of Grass and Pine Valleys (Potter and others, 1987) helped refine basis interpretations in those areas. The geologic base map of Paleozoic and Mesozoic igneous and sedimentary rocks, Tertiary volcanic and sedimentary rocks, and Cenozoic structures was simplified from Stewart and Carlson (1976b).
|Title||Map showing drill-hole depths, lithologic intercepts, and partial isopachs of basin fill in the Winnemucca 1 degree by 2 degrees Quadrangle, Nevada|
|Authors||B. C. Moring|
|Publication Subtype||USGS Numbered Series|
|Series Title||Miscellaneous Field Studies Map|
|Record Source||USGS Publications Warehouse|
