Maps showing interpretation, using R-mode factor analysis, of trace-element abundances in heavy-mineral concentrate samples, Delta 1° x 2° quadrangle, Utah

A set of heavy-mineral concentrate data for the Delta 1° x 2° quadrangle, Utah Conterminous U.S. Mineral Assessment Program (CUSMAP) project was compiled from results of analyses of samples collected during the National Uranium Resource Evaluation Program (SURE), as well as results obtained from samples collected more recently by the USGS. Data results, sampling methods, and analytical methods are provided in Abrogast and others, 1993; 1990; 1988a; 1988b). A similar report, discussing results obtained from stream-sediment samples, is presented in Zimbelman (1993a). The Delta 1° x 2° quadrangle, Utah (figure 1) contains a variety of hydrothermal mineral deposit types, including porphyry-, vein-, replacement-, and Carlin-type deposits. These deposit types have been worked for commodities including gold, silver, beryllium, uranium, lead, zinc, copper, manganese, and cadmium (Lindsey, 1977; Morris and Mogensen, 1978; Zimbelman and others, 1990; Zimbelman and others, 1988). Heavy-mineral concentrate and stream-sediment samples derived from these hydrothermally altered rocks typically contain many geochemical anomalies (for example, see Zimbelman 1993b, c, d). Element associations characterizing lithology and hydrothermal mineral deposits can be distinguished using R-mode factor analysis. This tool often is useful in reconnaissance-scale surveys where sample anomalies are often weak. and single-element distributions may not help to delineate targets. R-mode factors analysis can help identify geologic trends and areas most likely to contain the mineral deposits. R-mode factor analysis was performed on a data set of results of analyses for 19 elements in 643 samples and produced a six-factor model. These six factors represent the geochemical contributions to the data set provided by lithologic and mineralization processes, The distribution of samples that contain high scores for mineralization-related factors is widespread in the Delta quadrangle. These sample sites are though to relate to both known prospect and mineralization areas, as well as define new areas that are geochemically favorable to contain altered or mineralized rocks.
