Lidar Base Specification version 1. 3 Figure 4

By NGP Standards and Specifications February 2018 (approx.)
Lidar Base Specification v. 1.3: Figure 4. Graphic depiction of swath overlap
Original Thumbnail Medium

Detailed Description

Lidar Base Specification v. 1.3: Figure 4. Graphic depiction of swath overlap. Three light detection and ranging swaths are depicted with the edges colored blue, red, and green. Each adjacent pair of swaths shares one overlap region shown in gray.

Sources/Usage

Public Domain.
