St. Louis Area Earthquake Hazards Mapping Project Completed
In the St. Louis area of Missouri and Illinois the USGS partnered with a local and regional working group to produce urban earthquake hazard maps for the community.
The St. Louis area has experienced minor earthquake damage at least 12 times in the past 205 years (PDF, St. Louis University). The St. Louis metropolitan area, with a population of about 2.8 million, faces earthquake hazard from distant large earthquakes in the New Madrid and Wabash Valley seismic zones, as well as a closer region of diffuse historical and prehistoric seismicity to its south and east. Also, low attenuation of seismic energy in the region (seismic energy carries farther with less weakening of the signal than in the western U.S.) and a substantial number of historic older unreinforced brick and stone buildings make the St. Louis area vulnerable to moderate earthquakes at relatively large distances compared to the western United States.
This project was led by representatives from the Missouri University of Science and Technology Natural Hazards Mitigation Institute, the Illinois State Geological Survey, the Missouri Department of Natural Resources, the Central U.S. Earthquake Consortium (CUSEC) emergency managers, CUSEC State Geologists, CERI at the University of Memphis, and the USGS.
Local Geologic Variations Affect the Earthquake Hazard
Structures located in the Missouri and Mississippi River floodplains sitting on thick soft sediments will likely experience stronger ground shaking and a greater likelihood of liquefaction. Below St. Louis, bedrock is most commonly a hard 350 million-year-old limestone. Structures built on or near bedrock, such as in the upland areas out of the floodplains, will tend to have lower levels of earthquake ground shaking. Thus, variation in earthquake-shaking hazard in the area can be subdivided into two main groups defined by surficial geology: uplands and lowland river valleys.
At short periods (high frequency vibrations), seismic hazard is higher on the bluffs (uplands), mostly in the central and eastern parts of the study area, and exceeds 0.40g (ground shaking forces expressed as a percentage of the strength of the Earth’s gravitational force, g), while in the lowlands high-frequency shaking hazard is reduced (less than 0:40g, but still potentially damaging). At long periods (longer wavelength shaking; 1.0 second period waves), the uplands/lowlands trend is reversed with higher seismic hazard (greater than 0.25g) in the lowlands (see figure at right). This is especially true along the Mississippi River due to energy trapped in the thicker soft sediments, whereas being less than 0.25g in the uplands (thin soils).
Liquefaction hazard is characterized as very low (liquefaction unlikely) to severe (liquefaction very likely), with the severe liquefaction hazard occurring in the Mississippi, Missouri, and Meramec River floodplains where there are shallow water tables and 10–40-m-thick sequences of unconsolidated sands and gravels over sedimentary rocks.
Supplemental Documentation
- 2011 Implementation of a more efficient hazard calculation methodology and more extensive uncertainty analysis for the St. Louis region
- Paleoseismological Study in the St. Louis Region: Collaborative Research, M. Tuttle & Associates and the Eastern Region Climate/Hazards Team, USGS
- Comparing the 2002 and 2008 USGS Seismic Hazard Model in the St. Louis Area
- Report describing the St. Louis area surficial materials database (1.4MB PDF)
Geologic Maps for Missouri Quadrangles in St. Louis Area
Index Map for Missouri 7.5' Quads - Missouri Geological Survey
- Creve Coeur (1.7MB PDF)
- Alton (19.8MB PDF)
- Cahokia (10.1MB PDF)
- Chesterfield (1.9MB PDF)
- Clayton (13.9MB PDF)
- Elsah (19.3MB PDF)
- Florissant (14.5MB PDF)
- Grafton (13.5MB PDF)
- Kampville (11.4MB PDF)
- Kirkwood (13.9MB PDF)
- O'Fallon (12.1MB PDF)
- Oakville (13.3MB PDF)
- St. Charles (11.7MB PDF)
- Webster Groves (14.1MB PDF)
- Chesterfield-Manchester-House Springs-Maxville (9.3MB PDF)
- Wentzville (18.3MB PDF)
Geologic Maps for Illinois Quadrangles in St. Louis Area
Index Map for Illinois Quads - Illinois State Geological Survey
- Monks Mound (2.8MB PDF)
- Grafton (1.9MB PDF)
- Elsah (2.6MB PDF)
- Alton (14.4MB PDF)
- Bethalto (8.4MB PDF)
- Wood River (1.5MB PDF)
- Edwardsville (4.9MB PDF)
- Granite City (3.5MB PDF)
- Collinsville (9.7MB PDF)
- Cahokia (12.5MB PDF)
- French Village (14.3Mb PDF)
- O'Fallon (17.8MB PDF)
- Oakville (12.9MB PDF)
- Columbia (4.4MB PDF)
