Acoustic-waveform and acoustic-televiewer logs were obtained for a 400-meter interval of deeply buried basalt flows in three boreholes, and over shorter intervals in two additional boreholes located on the U.S. Department of Energy 's Hanford site in Benton County, Washington. Borehole-wall breakouts were observed in the unaltered interiors of a large part of individual basalt flows; however, several of the flows in one of the five boreholes had almost no breakouts. The distribution of breakouts observed on the televiewer logs correlated closely with the incidence of core disking in some intervals, but the correlation was not always perfect, perhaps because of the differences in the specific fracture mechanisms involved. Borehole-wall breakouts were consistently located on the east and west sides of the boreholes. The orientation is consistent with previous estimates of the principal horizontal-stress field in south-central Washington, if breakouts are assumed to form along the azimuth of the least principal stress. The distribution of breakouts repeatedly indicated an interval of breakout-free rock at the top and bottom of flows. Because breakouts frequently terminate at major low-angle fractures, the data indicate that fracturing may have relieved some of the horizontal stresses near flow tops and bottoms. Unaltered and unfractured basalt appeared to have a uniform compressional velocity of 6.0 + or - 0.1 km/sec and a uniform shear velocity of 3.35 + or - 0.1 km/sec throughout flow interiors. Acoustics-waveform logs also indicated that borehole-wall breakouts did not affect acoustic propagation along the borehole; so fracturing associated with the formation of breakouts appeared to be confined to a thin annulus of stress concentration around the borehole. Televiewer logs obtained before and after hydraulic fracturing in these boreholes indicated the extent of induced fractures, and also indicated minor changes to pre-existing fractures that may have been inflated during fracture generation.
|Title||Acoustic-televiewer and acoustic-waveform logs used to characterize deeply buried basalt flows, Hanford site, Benton County, Washington|
|Authors||Frederick L. Paillet|
|Publication Subtype||USGS Numbered Series|
|Series Title||Open-File Report|
|Record Source||USGS Publications Warehouse|
