Archive of bathymetry data collected in South Florida from 1995 to 2015

August 10, 2017


Land development and alterations of the ecosystem in south Florida over the past 100 years have decreased freshwater and increased nutrient flows into many of Florida's estuaries, bays, and coastal regions. As a result, there has been a decrease in the water quality in many of these critical habitats, often prompting seagrass die-offs and reduced fish and aquatic life populations. Restoration of water quality in many of these habitats will depend partly upon using numerical-circulation and sediment-transport models to establish water-quality targets and to assess progress toward reaching restoration targets. Application of these models is often complicated because of complex sea floor topography and tidal flow regimes. Consequently, accurate and modern sea-floor or bathymetry maps are critical for numerical modeling research. Modern bathymetry data sets will also permit a comparison to historical data in order to help assess sea-floor changes within these critical habitats. New and detailed data sets also support marine biology studies to help understand migratory and feeding habitats of marine life.

This data series is a compilation of 13 mapping projects conducted in south Florida between 1995 and 2015 and archives more than 45 million bathymetric soundings. Data were collected primarily with a single beam sound navigation and ranging (sonar) system called SANDS developed by the U.S. Geological Survey (USGS) in 1993. Bathymetry data for the Estero Bay project were supplemented with the National Aeronautics and Space Administration's (NASA) Experimental Advanced Airborne Research Lidar (EAARL) system. Data from eight rivers in southwest Florida were collected with an interferometric swath bathymetry system. The projects represented in this data series were funded by the USGS Coastal and Marine Geology Program (CMGP), the USGS South Florida Ecosystem Restoration Project- formally named Placed Based Studies, and other non-Federal agencies. The purpose of the data collection for all these projects was to support one or more of the following scientific aspects: numerical model applications, sea floor change analysis, or marine habitat investigations.

This report serves as an archive of processed bathymetry sounding data, digital bathymetric contours, digital bathymetric maps, sea floor surface grids, and formal Federal Geographic Data Committee (FGDC) metadata. Refer to the Abbreviations page for explanations of acronyms and abbreviations used in this report. Since 2006, the USGS St. Petersburg Coastal and Marine Science Center (SPCMSC) assigns a unique identifier or Field Activity Number (FAN) for each field data collection. Projects described in this report conducted prior to 2006 do not have a FAN.

Data from the 13 projects presented in this report provided critical hydrographic information to support multiple science projects in south Florida. The projects and the types of sounding data collected are:

  • Florida Bay (1995-1999) - single-beam
  • Lake Okeechobee (2001) - single-beam
  • Tampa Bay (2001-2004) - single-beam
  • Caloosahatchee River (2002)- single-beam
  • Estero Bay to Matlacha Pass and offshore to Wiggins Pass (2003) - single-beam and airborne lidar
  • North and Northwest Forks of the Loxahatchee and Lower St. Lucie Rivers (2003) - single-beam
  • South Charlotte Harbor and offshore Sanibel Island (2003-2004) - single-beam
  • Shark River and Trout Creek (2004) - single-beam and interferometric swath
  • Southwest Florida Rivers (2004) - interferometric swath
  • Offshore from Wiggins Pass to Cape Romano (2005) - single-beam
  • Ten Thousand Islands (2009) - single-beam
  • Lemon Bay (2011) - single-beam
  • Southwest Florida Rivers (2015) - interferometric swath
Publication Year 2017
Title Archive of bathymetry data collected in South Florida from 1995 to 2015
DOI 10.3133/ds1031
Authors Mark Erik Hansen, Nancy T. DeWitt, Billy J. Reynolds
Publication Type Report
Publication Subtype USGS Numbered Series
Series Title Data Series
Series Number 1031
Index ID ds1031
Record Source USGS Publications Warehouse
USGS Organization St. Petersburg Coastal and Marine Science Center
