Asthenosphere–lithosphere interactions in Western Saudi Arabia: Inferences from ³He/⁴He in xenoliths and lava flows from Harrat Hutaymah

Extensive volcanic fields on the western Arabian Plate have erupted intermittently over the last 30 Ma following emplacement of the Afar flood basalts in Ethiopia. In an effort to better understand the origin of this volcanism in western Saudi Arabia, we analyzed³He/⁴He, and He, CO₂ and trace element concentrations in minerals separated from xenoliths and lava flows from Harrat Hutaymah, supplemented with reconnaissance He isotope data from several other volcanic fields (Harrat Al Birk, Harrat Al Kishb and Harrat Ithnayn). Harrat Hutaymah is young (< 850 ka) and the northeasternmost of the volcanic fields. There is a remarkable homogeneity of ³He/⁴He trapped within most xenoliths, with a weighted mean of 7.54 ± 0.03 R_A (2σ, n = 20). This homogeneity occurs over at least eight different xenolith types (including spinel lherzolite, amphibole clinopyroxenite, olivine websterite, clinopyroxenite and garnet websterite), and encompasses ten different volcanic centers within an area of ~ 2500 km². The homogeneity is caused by volatile equilibration between the xenoliths and fluids derived from their host magma, as fluid inclusions are annealed during the infiltration of vapor-saturated magmas along crystalline grain boundaries. The notable exceptions are the anhydrous spinel lherzolites, which have a lower weighted mean ³He/⁴He of 6.8 ± 0.3 R_A (2σ, n = 2), contain lower concentrations of trapped He, and have a distinctly depleted light rare earth element signature. ³He/⁴He values of ~ 6.8 R_A are also commonly found in spinel lherzolites from harrats Ithnayn, Al Birk, and from Zabargad Island in the Red Sea. Olivine from non-xenolith-bearing lava flows at Hutaymah spans the He isotope range of the xenoliths. The lower ³He/⁴He in the anhydrous spinel lherzolites appears to be tied to remnant Proterozoic lithosphere prior to metasomatic fluid overprinting.

Elevated ³He/⁴He in the western harrats has been observed only at Rahat (up to 11.8 R_A; Murcia et al., 2013), a volcanic field situated above thinned lithosphere beneath the Makkah-Medinah-Nafud volcanic lineament. Previous work established that spinel lherzolites at Hutaymah are sourced near the lithosphere-asthenosphere boundary (LAB), while other xenolith types there are derived from shallower depths within the lithosphere itself (Thornber, 1992). Helium isotopes are consistent with melts originating near the LAB beneath many of the Arabian harrats, and any magma derived from the Afar mantle plume currently appears to be of minor importance.
