Background and geologic model for the 2024 U.S. Geological Survey assessment of undiscovered conventional petroleum resources in the Norphlet Formation, U.S. Gulf Coast

The Upper Jurassic Norphlet Formation is a stratigraphic unit located in the subsurface of the United States Gulf coastal plain and offshore Gulf of America (Gulf of Mexico). The Norphlet consists of clastic sediments derived from the southern Appalachian highlands, and was deposited in a continental dryland setting on the margins of the early Gulf of America rift basin. The formation contains a variety of sedimentary facies, including facies representing updip alluvial fans, wadis, red beds, and a widespread erg, or eolian sand sea. The erg facies form the primary reservoirs from which hydrocarbons sourced from the overlying Smackover Formation are produced. Development of the Norphlet began in earnest in the late 1960s, with new discoveries, including large fields at Flomaton, Hatters Pond, and Mobile Bay, continuing through the 2000s–2010s with the discovery of major oil fields in the offshore Desoto Canyon area. Onshore, Norphlet hydrocarbon traps typically are faulted salt anticlines, although many fields also have a stratigraphic trapping component because of the preservation of dune-scale bedforms. Thermal maturity across the Norphlet play varies significantly with depth, resulting in oil production transitioning downdip to natural gas liquids production, then dry gas production; production depths reach to greater than 21,000 feet. A 2024 U.S. Geological Survey assessment divided the Norphlet into four conventional assessment units defined by the type and frequency of trapping mechanisms, sedimentology, and thermal maturity of each area, with little potential for hydrocarbon development observed west of the Mississippi River. Although petroleum resources in the Norphlet were revised downward, it is probable that significant resources remain to be discovered.
