Characterisation of bituminite and testing reproducibility of vitrinite and bituminite reflectance measurements in organic‑carbon-rich intervals of the Kimmeridge Clay Formation: ICCP Identification of Dispersed Organic Matter Working Group round robin ex

Three round robin exercises (RRE) aimed at characterizing bituminite and testing the reproducibility of random vitrinite (VR_o %) and bituminite (BitR_o %) reflectance measurements on samples of dispersed organic matter from organic‑carbon rich shale intervals of Kimmeridge Clay Formation were conducted in 2016, 2018, and 2020. This work was conducted by the Identification of Dispersed Organic Matter Working Group (IDOM WG) of the International Committee for Coal and Organic Petrology (ICCP). The Kimmeridge Clay Formation represents the major marine source rock for the North Sea hydrocarbon province. Samples collected from Kimmeridge Bay, Dorset, England, United Kingdom and Filey Bay, North Yorkshire, England, United Kingdom outcrops and the 16/17–14 well in the Tiffany oil field, Viking Graben, North Sea, were analyzed by 19 to 23 participants in 15 to 17 laboratories from 14 to 15 countries. Samples contain moderate to high organic matter content [5.32 to 12.10 wt% total organic carbon (TOC) content] with thermal maturity ranging from immature to thermally mature (T_max 418 to 445 °C).

Participants used a standard description sheet to record bituminite morphological characteristics, including its form, size, mode of appearance, and impurities, for use in the revision of the bituminite definition. The usage of previously published classifications of bituminite types (e.g., bituminite I sensu Teichmüller and Ottenjann, 1977) in the RRE was not found to be helpful. The indistinct, amorphous character of boundaries of bituminite, and the poor preparation of whole rock pellets for the 2018 and 2020 RRE hampered identification of bituminite. Mean random BitR_o %, including outlying values, varied in all three RRE from 0.19 to 0.35% and is reported here for the first time. Application of the criterion standard deviation (SD)
