Collision structures of the Prince William terrane and Chugach terrane docking along the Shumagin and Unimak convergent margins, Alaska, USA

Western Alaska’s convergent margins are composed of tectonostratigraphic terranes. On land, terrane assembly is recognized along boundaries or sutures between neighboring geologic elements with distinctly different origins. In marine areas where rock outcrops are covered by sediment, recognizing terrane sutures is problematic. A fault in seismic dip line 5 of the ALEUT project has been interpreted as a terrane suture. It is imaged intermittently down to the 30+-km-deep plate interface. Processing of ALEUT strike line 7 revealed the suture at ~18 km depths extending 300 km along the margin. Upper structures in line 5 are like the structures of adjacent seismic transects where imaging is only 8−10 km deep. They were previously not recognized as the upper reaches of terrane sutures and show structural details obscured at greater depths. The composite data are the basis for a simple tectonic model of terrane docking.
