E-field ratio telluric survey near the Big Maria Mountains, Riverside County, California
The U.S. Geological Survey (USGS) under the Wilderness Act (Public Law 88-577) and the Federal Land Policy and Management Act (Public Law 94-579) has the responsibility, along with the U.S. Bureau of Mines, to survey certain areas in order to determine their mineral resource potential. This report presents results of three electric-field ratio telluric traverses conducted as part of the Bureau of Land Management Wilderness Program in the Big Maria Mountains, Riverside County, Calif. The telluric traverses were run on the southwest side of the Big Maria Mountains in an attempt to define the location of major buried faults near the eroded front of the range.
E-field ratio tellurics is a descriptive name applied to the electrical exploration technique used in this survey. The telluric method refers to the measurement of the earth's electric field generated by induction from natural electromagnetic waves arriving at the surface. The E-field ratio telluric method uses a receiving array of three electrodes spaced equidistant and inline. This array is, in effect, two colinear dipoles sharing a common electrode. The potential difference across each dipole is then proportional to the component of the telluric field in the direction of the array. This configuration permits the measurement of the ratio of the telluric field at each dipole in the direction of the dipole line, and hence the name. The traverse data is extended by moving the three-electrode array forward one dipole length so that the forward electrode becomes the center electrode for the next ratio measurement.
Electric-field data so obtained are proportional to the square root of the apparent resistivity of the earth at the location of the dipoles. However, because the apparent resistivity can be a function of the dipole direction, it is important to know the orientation of the dipoles with respect to major structures. Because the resistivity of fluid-saturated earth materials is largely dependent on the porosity of the rocks, the salinity of the pore fluid, and the presence of clays or similar material where surface conduction is high, alluvial fill, argillite and similar rocks tend to have low resistivities whereas igneous or high-grade metamorphic rocks have high resistivities. Variation in the electrical properties along a traverse may then be used to infer lithologic or structural changes.
Citation Information
Publication Year | 1981 |
---|---|
Title | E-field ratio telluric survey near the Big Maria Mountains, Riverside County, California |
DOI | 10.3133/ofr81961 |
Authors | Donald B. Hoover, Michael M. Broker, T. Stambaugh |
Publication Type | Report |
Publication Subtype | USGS Numbered Series |
Series Title | Open-File Report |
Series Number | 81-961 |
Index ID | ofr81961 |
Record Source | USGS Publications Warehouse |
