The North and East of Eocene West Side Fold Belt Assessment Unit (AU) of the Eocene Total Petroleum System of the San Joaquin Basin Province comprises all hydrocarbon accumulations within the geographic and stratigraphic limits of this confirmed AU. Oil and associated gas accumulations occur in Paleocene through early middle Miocene marine to nonmarine sandstones found on the comparatively stable northeast shelf of the basin. The assessment unit is located north and east of the thickest accumulation of Neogene sediments and the west side fold belt. The area enclosed by the AU has been affected by only mild deformation since Eocene time. Traps containing known accumulations are mostly low-relief domes, anticlines, and up-dip basin margin traps with faulting and stratigraphic components. Map boundaries of the assessment unit are shown in figures 19.1 and 19.2; this assessment unit replaces the Northeast Shelf of Neogene Basin play 1006, the East Central Basin and Slope North of Bakersfield Arch play 1010, and part of the West Side Fold Belt Sourced by Pre-middle Miocene Rocks play 1005 considered by the U.S. Geological Survey (USGS) in their 1995 National Assessment (Beyer, 1996). Stratigraphically, the AU includes rocks from the uppermost crystalline basement to the topographic surface. In the region of overlap with the Central Basin Monterey Diagenetic Traps Assessment Unit, the North and East of Eocene West Side Fold Belt AU extends from basement rocks to the top of the Temblor Formation (figs. 19.3 and 19.4). In map view, the northern boundary of the assessment unit corresponds to the northernmost extent of Eocene-age Kreyenhagen Formation. The northeast boundary is the eastern limit of possible oil reservoir rocks near the eastern edge of the basin. The southeast boundary corresponds to the pinch-out of Stevens sand of Eckis (1940) to the south, which approximately coincides with the northern flank of the Bakersfield Arch (fig. 19.1). The AU is bounded on the southwest by the limit of major west side structural deformation and to the northwest by the San Andreas Fault and the limit of hydrocarbon-prospective strata in the Coast Ranges. As described by Gautier and others (this volume, chapter 2), existing oil fields in the San Joaquin Basin Province were assigned to assessment units based on the identified petroleum system and reservoir rocks in each field. Vallecitos oil field in the extreme northwest corner of the basin was assigned to the Eocene Total Petroleum System, because oil analyses conducted for this San Joaquin Basin assessment indicate that Eocene oil charged the reservoir rocks (Lillis and Magoon, this volume, chapter 9). Some literature classifies the Vallecitos oil field as part of the northernmost fold of the basin’s west side fold belt (see, for example, Rentschler, 1985; Bartow, 1991), but because of the oil field’s spatial separation and differing trend from the west side fold belt, Vallecitos field was considered here to be within the North and East of Eocene West Side Fold Belt Assessment Unit rather than in the other assessment unit in the Eocene Total Petroleum System, the Eocene West Side Fold Belt. Primary fields in the assessment unit are defined as those containing hydrocarbon resources greater than the USGS minimum threshold for assessment (0.5 million barrels of oil); secondary fields contain smaller volumes of oil but constitute a significant show of hydrocarbons.
|Title||Eocene total petroleum system — North and East of the Eocene West Side Fold Belt Assessment Unit of the San Joaquin Basin Province|
|Authors||Donald L. Gautier, Allegra Hosford Scheirer|
|Publication Subtype||USGS Numbered Series|
|Series Title||Professional Paper|
|Record Source||USGS Publications Warehouse|
|USGS Organization||Energy Resources Program|
