Between February 1998 and April 1998, geophysical logs were collected in nine boreholes adjacent to the Berkley Products Superfund Site, West Cocalico Township, Lancaster County, Pa. Video surveys were conducted on four of the nine boreholes. The boreholes range in depth from 320 to 508 feet below land surface, are completed open holes, have ambient vertical flow of water, and penetrate a series of interbedded siltstone, sandstone, and conglomerate units. The purpose of collecting geophysical-log data was to help determine horizontal and vertical distribution of contaminated ground water migrating from known or suspected sources and to aid in the placement of permanent borehole packers. The primary contaminants were derived from paint waste that included pigment sludges and wash solvents. The chlorinated volatile organic compounds probably originated from the wash solvents.
Caliper logs and video surveys were used to locate fractures; inflections on fluid-resistivity and fluid-temperature logs were used to locate possible water-bearing fractures. Heatpulse-flowmeter measurements were used to verify the locations of water-producing or water-receiving zones and to measure rates of flow between water-bearing fractures. Single-point-resistance and natural-gamma logs provided information on stratigraphy. After interpretation of geophysical logs, video surveys, and driller's logs, permanent multiple-packer systems were installed in each borehole to obtain depth specific water samples from one or more water-bearing fractures in each borehole.
