Hanawaltite, Hg1+6Hg2+[Cl,(OH)]2O3 - A new mineral from the Clear Creek claim, San Benito County, California: Description and crystal structure

Hanawaltite, ideally Hg1+₆Hg²⁺O₃Cl₂, is orthorhombic, Pbma (57), with unit-cell parameters refined from powder data: a=11.790(3), b=13.881(4), c=6.450(2) Å, V=1055.7(6) ų, a:b:c =0.8494:1:0.4647, Z=4. The strongest six lines of the X-ray powder-diffraction pattern [d in Å (I)(hkl)] are: 5.25 (80)(111), 3.164 (60)(231), 3.053 (100)(041), 2.954 (70)(141), 2.681 (50)(401), and 2.411 (50)(232,341). The mineral is an extremely rare constituent in a small prospect pit near the long-abandoned Clear Creek mercury mine, New Idria district, San Benito County, California. It was found on a single-fracture surface where it is intimately associated with calomel, native mercury, cinnabar, montroydite, and quartz. Individual crystals are subhedral to anhedral, platy to somewhat bladed, and average about 50 μm in longest dimension. The largest known crystal is approximately 0.3×0.3 mm in size and is striated parallel [001]. Hanawaltite is opaque to translucent (on very thin edges), black to very dark brown–black in color, with a black to dark red–brown streak. Other physical properties include: metallic luster; cleavage {001} good; uneven fracture; brittle; nonfluorescent; H
