Landslide monitoring and runout hazard assessment by integrating multi-source remote sensing and numerical models: An application to the Gold Basin landslide complex, northern Washington

The landslide complex at Gold Basin, Washington, has been drawing considerable attention after a catastrophic runout of the nearby landslide at Oso, Washington, in 2014. To evaluate potential threats of the Gold Basin landslide to the campground down the slope, remote sensing and numerical modeling were integrated to monitor recent landslide activity and simulate hypothetical runout scenarios. Bare-earth LiDAR DEM (digital elevation model) differencing, InSAR (Interferometric Synthetic Aperture Radar), and offset tracking of SAR images reveal that localized collapses at the headscarps have been the primary type of landslide activity at Gold Basin from 2005 to 2019, and currently no signs indicative of movement of a large centralized block or a deep-seated main body were detected. The maximum horizontal deformation rate is 5 m/year occurring primarily from headscarp recession of the middle lobe, and the annual landsliding volume of the whole landslide complex averages 1.03 × 10⁵ m³. From three-dimensional limit equilibrium analysis of generalized terrace structures, the maximum landslide volume is estimated as 2.0 × 10⁶ m³. Simulations of hypothetical runout scenarios were carried out using the depth-averaged two-phase model D-claw with above-obtained landslide geometry constraints. The simulation results demonstrate that debris flows with volume less than 10⁵ m³ only pose limited threats to the campground, while volumes over 10⁶ m³ could cause severe damages. Consequently, the estimated maximum landslide volume of 2.0 × 10⁶ m³ suggests a potential risk to the campground nearby. Adaption of our methodology could prove useful for evaluating other similar landslides globally for hazards prevention and mitigation.
