Length-scale-dependent relationships between VS30 and topographic slopes in southern California

September 17, 2019

In engineering seismology, the time‐averaged shear‐wave velocity (⁠VS⁠) of the upper 30 m of the crust (⁠VS30⁠) is the primary parameter used in ground‐motion models to predict seismic site effects. ⁠VS30⁠ is typically derived from in situ recordings of VS⁠, although proxy‐based approaches (using geologic and/or geomorphometric classifications) are provisionally adopted when measurement‐based ⁠VS30⁠ are sparse or not readily available. Despite the acceptance of proxy approaches, there are limited studies that examine the empirical relationships between ⁠VS30⁠ and topographic attributes measured from various length scales and different resolutions of the digital elevation model. In this study, we examine the relationships between compiled ⁠VS30⁠ measurements from 218 sites in southern California and topographic metrics of slope and relief measured over various length scales. We find that the correlations between topographic metrics and ⁠VS30⁠ are weak but statistically significant. The correlations are improved when topographic slopes and relief are measured over length scales longer than typical hillslopes and ⁠VS30⁠ sites are separated by different geologic groups. This is likely because ⁠VS30⁠⁠, especially on the rock sites, is better reflected in topographic metrics that capture large‐scale topographic relief, as well as landscape positions such as hilltops and valley bottoms.

Publication Year 2019
Title Length-scale-dependent relationships between VS30 and topographic slopes in southern California
DOI 10.1785/0120190076
Authors Jessica Lin, Seulgi Moon, Alan Yong, Lingseng Meng, Paul Davies
Publication Type Article
Publication Subtype Journal Article
Series Title Bulletin of the Seismological Society of America
Index ID 70263729
Record Source USGS Publications Warehouse
USGS Organization Earthquake Science Center
