Report for borehole explosion data acquired in the 1999 Los Angeles Region Seismic Experiment (LARSE II), Southern California: Part I, description of the survey

January 1, 2001

The Los Angeles Region Seismic Experiment (LARSE) is a joint project of the U.S. Geological Survey (USGS) and the Southern California Earthquake Center (SCEC). The purpose of this project is to produce seismic images of the subsurface of the Los Angeles region down to the depths at which earthquakes occur, and deeper, in order to remedy a deficit in our knowledge of the deep structure of this region. This deficit in knowledge has persisted despite over a century of oil exploration and nearly 70 years of recording earthquakes in southern California. Understanding the deep crustal structure and tectonics of southern California is important to earthquake hazard assessment. Specific imaging targets of LARSE include (a) faults, especially blind thrust faults, which cannot be reliably detected any other way; and (b) the depths and configurations of sedimentary basins. Imaging of faults is important in both earthquake hazard assessment but also in modeling earthquake occurrence. Earthquake occurrence cannot be understood unless the earthquake-producing "machinery" (tectonics) is known (Fuis and others, 2001). Imaging the depths and configurations of sedimentary basins is important because earthquake shaking at the surface is enhanced by basin depth and by the presence of sharp basin edges (Wald and Graves, 1998, Working Group on California Earthquake Probabilities, 1995; Field and others, 2001). (Sedimentary basins are large former valleys now filled with sediment eroded from nearby mountains.) Sedimentary basins in the Los Angeles region that have been investigated by LARSE include the Los Angeles, San Gabriel Valley, San Fernando Valley, and Santa Clarita Valley basins.

The seismic imaging surveys of LARSE include recording of earthquakes (both local and distant earthquakes) along several corridors (or transects) through the Los Angeles region and also recording of man-made sources along these same corridors. Man-made sources have included airguns offshore and borehole explosions and vibrating-truck sources onshore. The two chief LARSE transects pass near recent moderate earthquakes, including the 1971 M 6.7 San Fernando, 1987 M 5.9 Whittier Narrows, 1991 M 5.8 Sierra Madre, and 1994 M 6.7 Northridge earthquakes. The first transect extended from San Clemente Island northeastward to the Mojave Desert (Line 1, Fig. 1), passing near the epicenter of the Whittier Narrows and Sierra Madre earthquakes. The second transect extended from west of San Clemente Island northward to the western Mojave Desert (Line 2, Figs. 1, 2), passing through the epicenter of the Northridge earthquake and near the epicenter of the San Fernando earthquake. Data along Line 1 were acquired during the years 1993-1994, and data along Line 2, during the years 1994–2000.

In this open-file report and that of Murphy and others (in preparation), we present the details of the October 1999 explosion survey along Line 2, which extended from Santa Monica Bay northward to the western Mojave Desert (Figs. 1, 2). This survey is referred to as LARSE II. In this survey, 93 borehole explosions were detonated along the main north-south line and along 5 auxiliary lines in the San Fernando Valley and Santa Monica areas. These explosions were recorded by ~1400 seismographs.

A variety of seismic instrumentation was used in these imaging surveys and was obtained from collaborators from around the world, including the Geological Survey of Canada (Ottawa, Canada), IRIS/PASSCAL (Socorro, NM), Lamont-Doherty Earth Observatory (Palisades, NY), Stanford University (Stanford, CA), SCEC (Los Angeles, CA), USGS (Menlo Park, CA, and Woods Hole, MA), University of Texas at El Paso (El Paso, TX), GeoForschungsZentrum (Potsdam, Germany), University of Karlsruhe (Karlsruhe, Germany), and University of Copenhagen (Copenhagen, Denmark). The reader is referred to Table 1 for instrumentation used in LARSE II.

Publication Year 2001
Title Report for borehole explosion data acquired in the 1999 Los Angeles Region Seismic Experiment (LARSE II), Southern California: Part I, description of the survey
DOI 10.3133/ofr01408
Authors Gary S. Fuis, Janice M. Murphy, David A. Okaya, Robert W. Clayton, Paul M. Davis, Kristina Thygesen, Shirley A. Baher, Trond Ryberg, Mark L. Benthien, Gerry Simila, J. Taylor Perron, Alan K. Yong, Luke Reusser, William J. Lutter, Galen Kaip, Michael D. Fort, Isa Asudeh, Russell Sell, John R. Van Schaack, Edward E. Criley, Ronald Kaderabek, Will M. Kohler, Nickolas H. Magnuski
Publication Type Report
Publication Subtype USGS Numbered Series
Series Title Open-File Report
Series Number 2001-408
Index ID ofr01408
Record Source USGS Publications Warehouse
USGS Organization Earthquake Science Center
