Seismic-wave strain, rotation, and gradiometry for the 4 March 2008 TAIGER explosions

May 1, 2009

Acceleration spatial gradients, horizontal strains, and horizontal rotation were computed using strong-motion array data from the 4 March 2008 TAIGER explosions in northeastern Taiwan and used in conjunction with the original three component acceleration data to perform a gradiometric analysis of the strong ground motion wave train. The analysis yields a complex, frequency-dependent view of the nature of seismic-wave propagation over short propagation distances that imply significant lateral velocity changes in structure. Areal strain and rotation about the vertical axis have equal amplitudes and suggest significant wave scattering within the confines of the river valley where the experiment was performed and/or significant departure from an axisymmetric explosion source. Gradiometry shows that the P wave arrives at the array 35° off-azimuth clockwise from the straight-line path and appears to have been refracted from the northern side of the valley. Large, slowly propagating secondary surface waves initially arrive 45° counterclockwise from the straight-line path but later arrivals are seen to propagate in all directions, including back toward the explosion source. A frequency-dependent radiation pattern for the triple-borehole explosion in comparison to the single-borehole explosion explains the differences in the maximum amplitudes between the sources seen in the acceleration data. The use of seismic strain and rotation with standard particle motion wave fields at a single location allows for a direct view of seismic-wave propagation that illuminates the true nature of the seismogram.

Publication Year 2009
Title Seismic-wave strain, rotation, and gradiometry for the 4 March 2008 TAIGER explosions
DOI 10.1785/0120080200
Authors Charles A. Langston, W.H.K. Lee, C.J. Lin, C.-C. Liu
Publication Type Article
Publication Subtype Journal Article
Series Title Bulletin of the Seismological Society of America
Index ID 70209189
Record Source USGS Publications Warehouse
