The Wenonah-Mount Laurel aquifer is being considered as a potential source of future water supply for the Camden, New Jersey, area. The deeper Potomac- Raritan-Magothy aquifer system is currently the major major source of water supply for the area, but its use may be curtailed or reduced by 35 percent of 1983 withdrawals through its designation by the New Jersey Department of Environmental Protection and Energy as "Water Supply Critical Area#2." Withdrawals from the Wenonah-Mount Laurel aquifer currently (1989) total about 7 million gallons per day. The anticipated use of this aquifer by communities with access to it, as an alternative supply, could increase to more than 14 million gallons per day by 2020. If the communities of Clayton and Glassboro decrease their withdrawals from the Potomac-Raritan-Magothy aquifer system by 50 percent or cease them entirely because of their proximity to saline water, the use of Wenonah-Mount Laurel aquifer could increase to greater than 15 million gallons per day by 2020. Simulation of the ground-water system indicates that the projected increase in withdrawals will cause cones of depression in the potentiometric surface of the Wenonah-Mount Laurel aquifer in the Camden metro- politan area by 2020 that extend to depths ranging from 10 feet above sea level to 60 feet below sea level. This represents a secline of about 40 to 100 feet thr 1990 conditions. Withdrawals in northeastern Burlington County will cause a large cone of depression that, by 2020, will extend to depths of about 220 feet below sea level, represent- ing a decline of about 140 feet from 1990 conditions. Simulation results indicate that water levels in the Wenonah-Mount Laurel aquifer near the Salem Nuclear Power Plant are somewhat insensitive to withdrawals elsewhere in the aquifer. In some areas, especially in Burlington County, the cones of depression have developed in proximity to the aquifer-outcrop area and could induce infiltration from streams crossing the outcrop. Because of the hydraulic connection to adjacent aquifers, future management plans need to be developed in a compre- hensive manner with regard to all aquifers. Further study of the aquifer in Salem County could provide additional information on the hydraulic connection to Delaware Bay and the potential for saltwater intrusion.
|Title||Simulated effects of projected withdrawals from the Wenonah-Mount Laurel aquifer on ground-water levels in the Camden, New Jersey, area and vicinity|
|Authors||A. S. Navoy|
|Publication Subtype||USGS Numbered Series|
|Series Title||Water-Resources Investigations Report|
|Record Source||USGS Publications Warehouse|
