Strong-motion data from the two Pingtung, Taiwan, earthquakes of 26 December 2006

January 1, 2008

1016 strong-motion records at 527 free-field stations and 131 records at 42 strong-motion arrays at buildings and bridges were obtained for the Pingtung earthquake doublet from the Taiwan Central Weather Bureau's dense, digital strong-motion network. We carried out standard processing of these strong-motion records at free-field stations. A data set, including the originally recorded files, processed data files, and supporting software and information, is archived online http:// We have not yet completed the processing of the strong-motion array data at buildings and bridges. However, some preliminary results and the strong-motion array data recorded at the second nearest instrumented building to the Pingtung earthquake doublet are shown. This paper is intended to document our data processing procedures and the online archived data files, so that researchers can efficiently use the data. We also include two preliminary analyses: (1) a comparison of ground motions recorded by multiple accelerographs at a common site, the TAP 117 station in Taipei, and (2) attenuation of the horizontal ground motions (peak acceleration and response spectra at periods of 0.2, 1.0, and 3.0 s) with respect to distance. Our comparison study of multiple recordings at TAP 117 indicates that waveform coherence among 20- and 24-bit accelerograph records is much higher as compared to records from 16-bit or 12-bit accelerographs, suggesting that the former are of better quality. For the 20- and 24-bit accelerographs, waveform coherence is nearly 1 over the frequency range 1 to 8 Hz for all components, and is greater than about 0.9 from 8 to 20 Hz for the horizontal component, but only from 8 to 12 Hz for the vertical component. Plots of pseudo-acceleration response spectra (PSA) as a function of distance, however, show no clear indication for a difference related to the performance level of the accelerographs. The ground-motions of the first event (Mw = 7.0) are comparable, or even somewhat lower, than those from the smaller second event (Mw = 6.9), consistent with the relative difference of the local magnitudes (ML = 6.96 and 6.99 for the first and second events, respectively). The ground motions from the first event are generally lower than those predicted from equations based on other in-slab subduction earthquakes, whereas the ground motions from the second event are closer to the predictions. Ground-motions for soil sites are generally larger than those from rock sites.

Publication Year 2008
Title Strong-motion data from the two Pingtung, Taiwan, earthquakes of 26 December 2006
DOI 10.3319/TAO.2008.19.6.595(PT)
Authors C.-F. Wu, W.H.K. Lee, D. M. Boore
Publication Type Article
Publication Subtype Journal Article
Series Title Terrestrial, Atmospheric and Oceanic Sciences
Index ID 70032275
Record Source USGS Publications Warehouse
