Two trenches were excavated across the 1906 trace of the San Andreas fault near fences that were displaced by the 1906 faulting. About 18 displacements equal to the 1906 displacement would account for the offset of a stream adjacent to one of the trenches. Review of divergent reports on the amount of fault displacement in 1906 at 7 localities indicates that right slip ranged from about 2 in (meters) to about 3 m at the main trace and was about 0.6 m on a subsidiary trace near one of the trench sites. Materials exposed in the trenches included Franciscan bedrock, Merced (?) sandstone, alluvial deposits, and modern soils. Visibility of the evidence for faulting covered a wide range. Faulting was expressed in the trenches as conspicuous color differences, abrupt termination of geologic units, fractures, gouge, granulation of rock, streaked contacts, rounding of rock fragments, and slickensides. Irregularly shaped masses of gouge and other materials found in both trenches may also be a manifestation of faulting. Neither caving of the walls nor the inflow of ground water were reliable indicators of the locations of faults in these trenches. The features exposed in the trenches clearly indicated the presence of an important zone of faults with geologically young displacements, but they were inadequate to identify with certainty the 1906 break or the probable 1838 break. For example, evidence of the 1906 rupture could not be seen in a unit 200 mm (millimeters) thick that is believed to predate 1906. The approximate location in the trenches of the 1906 zone of ruptures could, however, be inferred from surface morphology, historic records, and evidence in the trenches. A moderately sharp and steep contact between two surface soils, in itself suggestive of very young faulting, did not have a fault below it. Brass monuments were installed at the trench sites so that future surface ruptures can be related to the faults and other structures mapped in the trenches.
