Azimuthal square-array direct-current (dc) resistivity soundings were used to detect fractures in bedrock in the Mirror Lake watershed in Grafton County, New Hampshire. Soundings were conducted at a site where crystalline bedrock underlies approximately 7 m (meters) of glacial drift. Measured apparent resistivities changed with the orientation of the array. Graphical interpretation of the square-array data indicates that a dominant fracture set and (or) foliation in the bedrock is oriented at 030° (degrees). Interpretation of crossed square-array data indicates an orientation of 027° and an anisotropy factor of 1.31. Assuming that anisotropy is due to fractures, the secondary porosity is estimated to range from 0.01 to 0.10.
Interpretations of azimuthal square-array data are supported by other geophysical data, including azimuthal seismic-refraction surveys and azimuthal Schlumberger dc-resistivity soundings at the Camp Osceola well field. Dominant fracture trends indicated by these geophysical methods are 022° (seismic-refraction) and 037° (dc-resistivity). Fracture mapping of bedrock outcrops at a site within 250 m indicates that the maximum fracture-strike frequency is oriented at 030°.
The square-array dc-resistivity sounding method is more sensitive to a given rock anisotropy than the more commonly used Schlumberger and Wenner arrays. An additional advantage of the square-array method is that it requires about 65 percent less surface area than an equivalent survey using a Schlumberger or Wenner array.
