Volatile fluxes through the Big Bend section of the San Andreas Fault, California: helium and carbon-dioxide systematics

February 1, 2013

To investigate the source of volatiles and their relationship to the San Andreas Fault System (SAFS), 18 groundwater samples were collected from wells near the Big Bend section of the SAFS in southern California and analyzed for helium and carbon abundance and isotopes. Concentrations of 4He, corrected for air-bubble entrainment, vary from 4.15 to 62.7 (× 10− 8) cm3 STP g− 1 H2O. 3He/4He ratios vary from 0.09 to 3.52 RA (where RA = air 3He/4He), consistent with up to 44% mantle helium in samples. A subset of 10 samples was analyzed for the major volatile phase (CO2) — the hypothesized carrier phase of the helium in the mantle–crust system: CO2/3He ratios vary from 0.614 to 142 (× 1011), and δ13C (CO2) values vary from − 21.5 to − 11.9‰ (vs. PDB).

3He/4He ratios and CO2 concentrations are highest in the wells located in the Mil Potrero and Cuddy valleys adjacent to the SAFS. The elevated 3He/4He ratios are interpreted to be a consequence of a mantle volatile flux though the SAFS diluted by radiogenic He produced in the crust. Samples with the highest 3He/4He ratios also had the lowest CO2/3He ratios. The combined helium isotope, He–CO2 elemental relationships, and δ13C (CO2) values of the groundwater volatiles reveal a mixture of mantle and deep crustal (metamorphic) fluid origins. The flux of fluids into the seismogenic zone at high hydrostatic pressure may cause fault rupture, and transfer volatiles into the shallow crust.

We calculate an upward fluid flow rate of 147 mm a− 1 along the SAFS, up to 37 times higher than previous estimates (Kennedy et al., 1997). However, using newly identified characteristics of the SAFS, we calculate a total flux of 3He along the SAFS of 7.4 × 103 cm3 STP a− 1 (0.33 mol 3He a− 1), and a CO2 flux of 1.5 × 1013 cm3STP a− 1 (6.6 × 108 mol a− 1), ~ 1% of previous estimates. Lower fluxes along the Big Bend section of the SAFS suggest that the flux of mantle volatiles alone is insufficient to cause the super hydrostatic pressure in the seismogenic zone; however, results identify crustal (metamorphic) fluids as a major component of the CO2 volatile budget, which may represent the additional flux necessary for fault weakening pressure in the SAFS.

Publication Year 2013
Title Volatile fluxes through the Big Bend section of the San Andreas Fault, California: helium and carbon-dioxide systematics
DOI 10.1016/j.chemgeo.2012.09.007
Authors Justin T. Kulongoski, David R. Hilton, Peter H. Barry, Bradley K. Esser, Darren Hillegonds, Kenneth Belitz
Publication Type Article
Publication Subtype Journal Article
Series Title Chemical Geology
Index ID 70094691
Record Source USGS Publications Warehouse
USGS Organization California Water Science Center
