Water-Resources Data and Hydrogeologic Setting at the Raleigh Hydrogeologic Research Station, Wake County, North Carolina, 2005-2007

Water-resources data were collected to describe the hydrologic conditions at the Raleigh hydrogeologic research station, located in the Piedmont Physiographic Province of North Carolina. Data collected by the U.S. Geological Survey and the North Carolina Department of Environment and Natural Resources, Division of Water Quality, from May 2005 through September 2007 are presented in this report. Three well clusters and four piezometers were installed at the Raleigh hydrogeologic research station along an assumed flow path from recharge to discharge areas. Each well cluster includes four wells to monitor the regolith, transition zone, and shallow and deep bedrock. Borehole, surface, and waterborne geophysics were conducted to examine the lithology and physical properties of the bedrock and to determine the aerial extent of near vertical diabase dikes. Slug tests were conducted in the wells at each cluster to determine the hydraulic conductivity of the formation tapped by each well. Periodic water-level altitudes were measured in all wells and in four piezometers. Continuous hourly water levels were measured in wells for variable periods of time during the study, and a surface-water gage collected 15-minute stage data from April to June 2006. In October 2005 and April 2006, water-quality samples were collected from a tributary and in all wells at the Raleigh hydrogeologic research station. Continuous water-quality data were collected hourly in three wells from December 2005 through January 2007 and every 15 minutes in the tributary from May to June 2006. In August 2006, streambed temperatures and drive-point ground-water samples were collected across lines of section spanning the Neuse River.
