Erosion Monitoring along the Coosa River, Alabama, using Terrestrial Light Detection and Ranging (T-LiDAR) Technology, 2014-2017
These datasets contain XYZ locations and other attributes of points from topographic bank surveys at six sites downstream from three dams on the Coosa River in Alabama, from October 2014 through July 2017. At the four sites downstream from H. Neely Henry and Walter Bouldin Dams, topographic data were collected using a motion-compensated LiDAR (MC-LiDAR) system mounted on a marine survey vessel equipped with an inertial navigation system (INS). Data were collected as the vessel traversed the river along a survey line near the site. Data collection software integrated and stored the range and angular measurements from the LiDAR, and the horizontal and vertical position and attitude data of the vessel from the INS in real time. Data processing required computer software to extract topography data from the raw data files and to summarize and map the information. At the two sites downstream from Logan Martin Dam, topographic data were collected using a tripod-based terrestrial LiDAR (T-LiDAR) system at several tripod setups distributed throughout the reach. Data collection software integrated and stored the range and angular measurements from the T-LiDAR. Computer software was utilized to process the raw data, align the various scans in reference to one another, and extract the topography data in a usable format. Point cloud comparison software was then used to compute the distance and volume gain or loss between surveys.
Citation Information
| Publication Year | 2019 |
|---|---|
| Title | Erosion Monitoring along the Coosa River, Alabama, using Terrestrial Light Detection and Ranging (T-LiDAR) Technology, 2014-2017 |
| DOI | 10.5066/F7GF0SS8 |
| Authors | Daniel M Wagner, Richard J Huizinga |
| Product Type | Data Release |
| Record Source | USGS Digital Object Identifier Catalog |
| USGS Organization | Lower Mississippi-Gulf Water Science Center - Nashville, TN Office |
Related Content
Erosion monitoring along selected bank locations of the Coosa River in Alabama using terrestrial light detection and ranging (T–lidar) technology, 2014–17
Related Content
- Publications
Erosion monitoring along selected bank locations of the Coosa River in Alabama using terrestrial light detection and ranging (T–lidar) technology, 2014–17
The Alabama Power Company operates a series of dams on the Coosa River in east central Alabama. Seven dams impound the river to form six reservoirs: Weiss Lake, H Neely Henry Lake, Logan Martin Lake, Lay Lake, Lake Mitchell, and Lake Jordan. Streamflow below these reservoirs is primarily controlled by power generation at the dams, and there is ongoing concern about the stability of selected streamAuthorsRichard J. Huizinga, Daniel M. Wagner - Connect
