Flood-inundation maps for the Peckman River in the Townships of Verona, Cedar Grove, and Little Falls, and the Borough of Woodland Park, New Jersey, 2014
Digital flood-inundation maps for an approximate 7.5-mile reach of the Peckman River in New Jersey, which extends from Verona Lake Dam in the Township of Verona downstream through the Township of Cedar Grove and the Township of Little Falls to the confluence with the Passaic River in the Borough of Woodland Park, were created by the U.S. Geological Survey (USGS) in cooperation with the New Jersey Department of Environmental Protection. The flood-inundation maps, which can be accessed through the USGS Flood Inundation Mapping Science Web site at http://water.usgs.gov/osw/flood_inundation/ depict estimates of the probable areal extent and depth of flooding corresponding to selected water levels (stages) at the USGS streamgage on the Peckman River at Ozone Avenue at Verona, New Jersey (station number 01389534). Near-real-time stages at this streamgage may be obtained on the Internet from the USGS National Water Information System at http://waterdata.usgs.gov/.
Flood profiles were simulated for the stream reach by means of a one-dimensional step-backwater model. The model was calibrated using the most current stage-discharge relations at USGS streamgages on the Peckman River at Ozone Avenue at Verona, New Jersey (station number 01389534) and the Peckman River at Little Falls, New Jersey (station number 01389550). The hydraulic model was then used to compute eight water-surface profiles for flood stages at 0.5-foot (ft) intervals ranging from 3.0 ft or near bankfull to 6.5 ft, which is approximately the highest recorded water level during the period of record (19792014) at USGS streamgage 01389534, Peckman River at Ozone Avenue at Verona, New Jersey. The simulated water-surface profiles were then combined with a geographic information system digital elevation model derived from light detection and ranging (lidar) data to delineate the area flooded at each water level.
The availability of these maps along with Internet information regarding current stage from the USGS streamgage provides emergency management personnel and residents with information, such as estimates of inundation extents, based on water stage, that is critical for flood response activities such as evacuations and road closures, as well as for post-flood recovery efforts.
|Flood-inundation maps for the Peckman River in the Townships of Verona, Cedar Grove, and Little Falls, and the Borough of Woodland Park, New Jersey, 2014
|Kara M. Watson, Michal J Niemoczynski
|USGS Digital Object Identifier Catalog
|New Jersey Water Science Center
