Map showing general chemical quality of ground water in the Kaiparowits coal-basin area, Utah

This is one of a series of maps that describe the geology and related natural resources in the Kaiparowits coal-basin area. Chemical analyses of water from about 40 widely scattered springs, 20 coal-exploration holes in the Kaiparowits Plateau, and 7 water wells in the vicinity of the communities of Escalante and Glen Canyon were used to compile this map. All the water samples were from depths of less than 1,000 feet (305 m). Water-quality data were also available from a number of petroleum wells and exploration holes more than 5,000 feet (1,524 m) deep; however, those data were used with considerable discretion because water produced by deep petroleum wells and exploration holes usually is more saline than water found at shallower depths at the drilling sites.

Most of the chemical analyses used were collected by the U.S. Geological Survey in cooperation with State, local, and other Federal agencies. Published sources of data included Phoenix (1963), Iorns, Hembree, and Phoenix (1964), Cooley (1965), Feltis (1966), and Goode (1966, 1969), and the Environmental Impact Statement of the proposed Kaiparowits power project (U.S. Bureau of Land Management, 1976).

Little or no ground-water-quality data were available for large areas in the Kaiparowits coal basin. In those areas, the indicated ranged of dissolved-solids concentrations in water from springs and wells are inferred largely from the geology as compiled by Stokes (1964) and Hackman and Wyant (1973). This is especially true for those areas where the designated ranges of dissolved-solids concentrations are 100-1,000 and 500-3,000 mg/l (milligrams per liter).

El Paso Natural Gas Co., Resources Co., Kaiser Engineers, and Southern California Edison Co. provided ground-water samples and specific water-quality data collected from their exploratory drill holes on the Kaiparowits Plateau. The cooperation of those firms is gratefully acknowledged.
