Maps showing mineral resource assessment for porphyry and stockwork deposits of copper, molybdenum, and tungsten and for stockwork and disseminated deposits of gold and silver in the Butte 1° x 2° quadrangle, Montana

This report documents the assessment for potential occurrences of undiscovered porphyry and stockwork deposits of copper, molybdenum, and tungsten (porphyry Cu-Mo-W) and stockwork and disseminated deposits of gold and silver (disseminated Au-Ag) in the Butte 1 °X2° quadrangle. The Butte quadrangle, in west-central Montana, is one of the best known mineral producing regions in the U.S. Mining districts in the quadrangle, including the world famous Butte or Summit Valley district, have produced a variety of metallic and nonmetallic mineral commodities valued at more than $6.4 billion (at the time of production). Because of its importance as a mineral producing region, the Butte quadrangle was selected for study by the U.S. Geological Survey under the Conterminous United States Mineral Assessment Program (CUSMAP). Under this program, new data on geology, geochemistry, geophysics, geochronology, mineral resources, and remote sensing were collected and synthesized. The field and laboratory studies were supported, in part, by funding from the Geologic Framework and Synthesis Program and the Wilderness Program. The methods used in this resource assessment for porphyry Cu-Mo-W and disseminated Au-Ag deposits in the quadrangle include a compilation of all data, the development of descriptive occurrence models, and the analysis of data using techniques provided by a Geographic Information System (GIS).

This map is one of several maps on the Butte 1 °X2° quadrangle. Other deposit types have been assessed for the Butte quadrangle, and maps (U.S. Geological Survey (USGS) Miscellaneous Investigation Series Maps) for each of the following have been prepared: Vein and replacement deposits of gold, silver, copper, lead, zinc, manganese, and tungsten (Elliott, Wallace, and others, 1992a) and skarn deposits of gold, silver, copper, tungsten, and iron (Elliott and others, 1992b ). Other publications resulting from this study include linear features map (Rowan and others, 1991 ); limonite and hydrothermal alteration map (Rowan and Segal, 1989); mineral occurrence maps (Elliott and others, 1986; Elliott, Loen, and others, 1992); and geologic maps (Wallace, 1987; Wallace and others, 1987).
