Bathymetric contour maps, surface area and capacity tables, and bathymetric change maps for selected water-supply lakes in Missouri, 2022–23

January 23, 2025

Bathymetric data were collected at 13 water-supply lakes around the periphery of Missouri by the U.S. Geological Survey in cooperation with the Missouri Department of Natural Resources and various local agencies, as part of a multiyear effort to establish or update the surface area and capacity tables for the surveyed lakes. Surveys were carried out during the months of April and May in 2022 and 2023. All but two of the lakes had been surveyed previously by the U.S. Geological Survey, and the recent surveys were compared to the earlier surveys to document the changes in the bathymetric surface and capacity of the lake.

Bathymetric data were collected using a high-resolution multibeam mapping system mounted on a boat. Supplemental depth data at three of the lakes were collected in shallow areas with an acoustic Doppler current profiler on a remote-controlled boat. Data points from the various sources were exported at a gridded data resolution appropriate to each lake, either 0.82 foot, 1.64 feet, or 3.28 feet. Data outside the multibeam survey extent and greater than the surveyed water-surface elevation were obtained from data collected using aerial light detection and ranging (lidar) point cloud data. A linear enforcement technique was used to add points to the dataset in areas of sparse data (the upper ends of coves where the water was shallow or aquatic vegetation precluded data acquisition) based on surrounding multibeam and upland data values. The various point datasets were used to produce a three-dimensional triangulated irregular network surface of the lake-bottom elevations for each lake. A surface area and capacity table was produced from the three-dimensional surface for each lake showing surface area and capacity at specified lake water-surface elevations. Various quality-assurance tests were conducted to ensure quality data were collected with the multibeam, including beam angle checks and patch tests. Additional quality-assurance tests were conducted on the gridded bathymetric data from the survey, the bathymetric surface created from the gridded data, and the contours created from the bathymetric survey.

Publication Year 2025
Title Bathymetric contour maps, surface area and capacity tables, and bathymetric change maps for selected water-supply lakes in Missouri, 2022–23
DOI 10.3133/sir20245114
Authors Benjamin C. Rivers, Richard J. Huizinga, Garett J. Waite
Publication Type Report
Publication Subtype USGS Numbered Series
Series Title Scientific Investigations Report
Series Number 2024-5114
Index ID sir20245114
Record Source USGS Publications Warehouse
USGS Organization Central Midwest Water Science Center
