Coal resources for the Chemard Lake (Naborton No. 2) coal zone of the lower Wilcox group (Paleocene), northwestern Louisiana

The lower part of the Wilcox Group of northwest Louisiana contains shallow (less than 500 ft) coal deposits that are mined for use in mine-mouth electric power-generating plants. The coal deposits, which are lignite A in apparent rank (Pierce et al., 2011), occur on the eastern part of the Sabine uplift (Figure 1). The coal zones and associated strata in the assessment area generally dip away from the axis of the Red River-Bull Bayou dome that is located in the north-central part of the Louisiana Sabine assessment area (Figure 1). This assessment area includes parts of four parishes: De Soto, Red River, Natchitoches, and Sabine (Figure 2). The assessment area was selected because of its proximity to current mining areas and the availability of stratigraphic data in the area. The assessment area is roughly 60 miles long and 15 miles wide and generally extends across the central-eastern part of the Sabine uplift in northwest Louisiana (Figure 2). More than 950 stratigraphic records from rotary and core drill holes were used to assess the coal resources of the Louisiana Sabine area. Of these, 210 are public data points and are located in or near the areas that have been permitted or proposed for surface mining (Figure 2; Appendix 1). Most of the stratigraphic data used for this assessment were provided to the U.S. Geological Survey (USGS) on a confidential basis by various coal companies for use in regional studies.
