Comparison of two precipitation gage networks in Cook County, Illinois

The Cook County Precipitation Network is a set of 25 precipitation gages established within Cook County, Illinois, on approximately a 5- to 7-mile square grid and used by the U.S. Army Corps of Engineers to help account for diversions of water from Lake Michigan to the State of Illinois. The transition from the precipitation gage network operated by the Illinois State Water Survey to the precipitation gage network operated by the U.S. Geological Survey (USGS) was compared for periods of overlapping data. This transition took place from May through September during the 2019 water year. The USGS was able to establish replacement precipitation gages at 17 of the 25 sites by the conclusion of the overlapping operational period.

The double-mass curve method was used to compare the two networks by creating a graph of the cumulated data collected by the Illinois State Water Survey and the comparable data collected by the USGS. Breaks in the double-mass curve method are caused by a change in the relation between variables. The eight sites that were installed following the overlapping period have a gap in the recorded data; however, the slope of the line for each of the eight sites is nearly equivalent to the previous data. In general, the cumulated precipitation data from the two networks were similar. Three sites had greater than 8-percent difference in their cumulative data ratios, located at Cicero, Ping Tom Park at Chicago, and South Shore, Ill.
