Digital elevation models of the Pre-Eruption 2000 Crater and 2004-07 Dome-Building Eruption at Mount St. Helens, Washington, USA

Presented in this report are 27 digital elevation model (DEM) datasets for the crater area of Mount St. Helens. These datasets include pre-eruption baseline data collected in 2000, incremental model subsets collected during the 2004–07 dome building eruption, and associated shaded-relief image datasets. Each dataset was collected photogrammetrically with digital softcopy methods employing a combination of manual collection and iterative compilation of x,y,z coordinate triplets utilizing autocorrelation techniques. DEM data points collected using autocorrelation methods were rigorously edited in stereo and manually corrected to ensure conformity with the ground surface. Data were first collected as a triangulated irregular network (TIN) then interpolated to a grid format. DEM data are based on aerotriangulated photogrammetric solutions for aerial photograph strips flown at a nominal scale of 1:12,000 using a combination of surveyed ground control and photograph-identified control points. The 2000 DEM is based on aerotriangulation of four strips totaling 31 photographs. Subsequent DEMs collected during the course of the eruption are based on aerotriangulation of single aerial photograph strips consisting of between three and seven 1:12,000-scale photographs (two to six stereo pairs). Most datasets were based on three or four stereo pairs. Photogrammetric errors associated with each dataset are presented along with ground control used in the photogrammetric aerotriangulation. The temporal increase in area of deformation in the crater as a result of dome growth, deformation, and translation of glacial ice resulted in continual adoption of new ground control points and abandonment of others during the course of the eruption. Additionally, seasonal snow cover precluded the consistent use of some ground control points.
