Evaluating chlorophyll fluorescence sensors as a proxy for chlorophyll a concentrations in the Illinois River, Illinois, water years 2018–24

The U.S. Geological Survey deployed instream chlorophyll fluorescence sensors on the Illinois River in Illinois to better understand the formation, dynamics, and persistence of riverine algal blooms. At five sensor locations across four U.S. Geological Survey streamgages, chlorophyll fluorescence (fChl) sensors were set to measure instantaneous fChl in micrograms per liter as chlorophyll at 15-minute intervals. These sensors estimate fChl based on the fluorescence response of algal pigments but do not directly measure chlorophyll a (Chl) concentrations or algal biomass. To evaluate the reliability of fChl as a proxy for Chl, fChl measurements were compared to laboratory-measured Chl concentrations. These Chl concentrations were obtained from water-quality samples collected at the sensor locations and analyzed using the standard chromatographic-fluorometric method with acetone extraction. A total of 209 paired fChl and Chl observations were analyzed using Pearson’s correlation and model II regression. Statistically significant, positive correlations (Pearson’s correlation coefficient of 0.68–0.95) were detected at all sensor locations, indicating that fChl generally tracked with Chl. However, model II regression detected proportional and fixed bias at three of the five locations and proportional bias at another location. At locations with proportional biases, model II regression slopes were less than 1, indicating that fChl increasingly underestimated Chl as concentrations increased; however, paired observations at high Chl concentrations were sparse. Substantial variability in bias was also observed across sensor locations with slopes ranging from 0.43 to 0.93. Overall, the results indicated that fChl correlates well with Chl in the Illinois River, but fChl may not reliably represent Chl concentrations without adjustment. For applications requiring accurate Chl estimates, a sensor location-specific surrogate model could be beneficial. These findings underscore the importance of field validation, consistent sensor placement, and careful interpretation of fChl data, particularly when reported in micrograms per liter.
