Flood-inundation maps for the Wabash River at Memorial Bridge at Vincennes, Indiana

Digital flood-inundation maps for a 10.2-mile reach of the Wabash River from Sevenmile Island to 3.7 mile downstream of Memorial Bridge (officially known as Lincoln Memorial Bridge) at Vincennes, Indiana, were created by the U.S. Geological Survey (USGS) in cooperation with the Indiana Office of Community and Rural Affairs. The inundation maps, which can be accessed through the USGS Flood Inundation Mapping Science Web site at http://water.usgs.gov/osw/flood_inundation/ depict estimates of the areal extent and depth of flooding corresponding to selected water levels (stages) at USGS streamgage 03343010, Wabash River at Memorial Bridge at Vincennes, Ind. Near-real-time stages at this streamgage may be obtained on the Internet from the USGS National Water Information System at http://waterdata.usgs.gov/ or the National Weather Service (NWS) Advanced Hydrologic Prediction Service at http:/water.weather.gov/ahps/, which also forecasts flood hydrographs at this site.

For this study, flood profiles were computed for the Wabash River reach by means of a one-dimensional stepbackwater model. The hydraulic model was calibrated by using the most current stage-discharge relations at USGS streamgage 03343010, Wabash River at Memorial Bridge at Vincennes, Ind., and preliminary high-water marks from a high-water event on April 27, 2013. The calibrated hydraulic model was then used to determine 19 water-surface profiles for flood stages at 1-foot intervals referenced to the streamgage datum and ranging from 10 feet (ft) or near bankfull to 28 ft, the highest stage of the current stage-discharge rating curve. The simulated water-surface profiles were then combined with a Geographic Information System (GIS) digital elevation model (DEM, derived from Light Detection and Ranging [lidar] data having a 0.98-ft vertical accuracy and 4.9-ft horizontal resolution) in order to delineate the area flooded at each water level.

The availability of these maps—along with Internet information regarding current stage from the USGS streamgage 03343010, and forecast stream stages from the NWS AHPS—provides emergency management personnel and residents with information that is critical for flood response activities such as evacuations and road closures, as well as for post-flood recovery efforts.
