Geologic map of the Sunnymead 7.5' quadrangle, Riverside County, California

January 1, 2001

Open-File Report 01-450 contains a digital geologic map database of the Sunnymead 7.5’ quadrangle, Riverside County, California that includes:

ARC/INFO (Environmental Systems Research Institute, http:/ version 7.2.1 coverages of the various elements of the geologic map.
A Postscript file to plot the geologic map on a topographic base, containing a Correlation of Map Units diagram (CMU), a Description of Map Units (DMU), and an index map.
Portable Document Format (.pdf) files of:
a. This Readme; includes in Appendix I, data contained in sun_met.txt

b. The same graphic as plotted in 2 above. Test plots have not produced 1:24,000-scale map sheets. Adobe Acrobat page size setting influences map scale.

The Correlation of Map Units and Description of Map Units is in the editorial format of USGS Geologic Investigations Series (I-series) maps but has not been edited to comply with I-map standards. Within the geologic map data package, map units are identified by standard geologic map criteria such as formation-name, age, and lithology. Where known, grain size is indicated on the map by a subscripted letter or letters following the unit symbols as follows: lg, large boulders; b, boulder; g, gravel; a, arenaceous; s, silt; c, clay; e.g. Qyfa is a predominantly young alluvial fan deposit that is arenaceous. Multiple letters are used for more specific identification or for mixed units, e.g., Qfysa is a silty sand. In some cases, mixed units are indicated by a compound symbol; e.g., Qyf2sc. Marine deposits are in part overlain by local, mostly alluvial fan, deposits and are labeled Qomf. Grain size follows f.

Even though this is an Open-File Report and includes the standard USGS Open-File disclaimer, the report closely adheres to the stratigraphic nomenclature of the U.S. Geological Survey. Descriptions of units can be obtained by viewing or plotting the .pdf file (3b above) or plotting the postscript file (2 above).

Publication Year 2001
Title Geologic map of the Sunnymead 7.5' quadrangle, Riverside County, California
DOI 10.3133/ofr01450
Authors Douglas M. Morton, Jonathan C. Matti
Publication Type Report
Publication Subtype USGS Numbered Series
Series Title Open-File Report
Series Number 2001-450
Index ID ofr01450
Record Source USGS Publications Warehouse
USGS Organization Geology, Minerals, Energy, and Geophysics Science Center
