Lithologic log and drilling information for the Marble exploration hole 3, U15 area, Nevada Test Site, Nye County, Nevada

The Marble exploration hole 3 is in the northern part of the Tippipah Spring NE 7-1/2 minute quadrangle at the north end of Yucca Valley (fig.1).  The collar elevation of the hole is about 5,316 feet and has the approximate Nevada State coordinates of N. 903,093 and E. 674,870. The hole was drilled to determine the physical and chemical properties of the marble within a radius of 200 feet of a point 950 feet below the surface.

The exploration hole is 978 feet deep and was drilled from June 12 to July 8, 1959, by Minerals Engineering Co. of Grand Junction, Colorado, using conventional NX coring equiipment and a Portadrill 2,500 drill rig. Water-base bentonitic mud was used as the drilling fluid in the upper part of the hole. Clear water was used after circulation became unrestorable below 200 feet. The hole was cased from surface to 20 feet. The drilling rate during coring ranged from 2.0 to 19.3 minutes per foot and averaged 4.6 minutes per foot (table 1). The core recovered was excellent in quality and quantity. The average core recovery is 92.7 percent (table 2).
