Lunar analog study using portable gamma-ray neutron detector: Radiochemical mapping of silicic-to-basaltic volcanic terrains in the San Francisco Volcanic Field, Arizona

Studying lunar silicic volcanism provides key insights into the Moon’s crustal evolution, magmatic processes, and volcanic history. The Lunar-VISE (Lunar Vulkan Imaging and Spectroscopy Explorer) mission will investigate the Gruithuisen domes, a unique lunar region hypothesized to have formed through silicic volcanism. Using instruments on a Firefly Aerospace lander and a Honeybee Robotics rover, Lunar-VISE will analyze mineralogy, geochemistry, and surface properties to determine the origin and evolution of the domes, with a gamma-ray and neutron spectrometer (LV-GRNS) among its payload instruments.

In preparation for this mission, we conducted preliminary fieldwork using a handheld gamma-ray neutron detector with NaI(Tl) and CsLiYCl:Ce (CLYC) scintillators. This study focuses on various rhyolitic and basaltic volcanic centers in the San Francisco Volcanic Field (SFVF) near Flagstaff, Arizona—specifically Sugarloaf Peak, Bonito Lava Flow, and Robinson Mountain, a region containing several well-characterized lunar analog sites. The SFVF was selected for this study due to its broad compositional diversity spanning basaltic to rhyolitic compositions, its well-preserved volcanic morphologies, and its extensive use in previous NASA field campaigns and astronaut training exercises, making it an ideal terrestrial laboratory for testing planetary exploration techniques. We measured natural radioactivity, specifically from potassium (K), thorium (Th), and uranium (U) and other elements in their decay chains, which serve as diagnostic tracers of magmatic differentiation and crustal evolution processes, to assess geochemical variability across compositionally diverse terrains. The detector’s sensitivity was assessed across varying concentration levels.

Regionally averaged concentrations of radioisotopes were determined by gamma-ray spectroscopy at selected sites. Our measurements reveal significant compositional variations between sites, with Sugarloaf Peak (rhyolitic, silicic dome) exhibiting the highest average radioisotope concentrations (K: 3.29 ± 0.24 wt%, U: 14.35 ± 1.81 ppm, Th: 27.14 ± 2.43 ppm), while Bonito Lava Flow (K: 1.13 ± 0.08 wt%, U: 3.86 ± 0.52 ppm, Th: 7.52 ± 1.02 ppm), and Robinson Mountain (K: 1.46 ± 0.16 wt%, U: 5.59 ± 1.06 ppm, Th: 11.75 ± 1.98 ppm) show lower concentrations aligned with basaltic compositions. Gamma-ray fluxes were elevated by a factor of approximately three to four at Sugarloaf Peak relative to nearby basaltic terrains, consistent with expected geochemical differentiation patterns. Furthermore, at meter scales, proximity to geological features significantly affects measurements. Th concentrations adjacent to a cliff face at Sugarloaf’s base were 28% higher than values measured 3-5 meters away from the same feature, demonstrating localized compositional heterogeneity. Analysis of station-by-station measurements reveals that K, U, and Th concentrations show an elevation trend at Robinson Mountain and generally higher concentrations near Sugarloaf Peak’s summit, suggesting progressive magmatic differentiation and/or the presence of more evolved lithologies at higher elevations.

By mapping these elements on Earth using GRNS, we aim to optimize measurement techniques for Lunar-VISE and similar rover-borne missions by demonstrating the applicability of portable GRNS instruments for planetary surface exploration in an analog environment.
