The magmatic-hydrothermal system of the Three Sisters volcanic cluster, Oregon, imaged from field gravity measurements

From 2019 to 2024, gravity surveys were conducted at the Three Sisters volcanic cluster (TSVC), measuring 246 gravity sites using a spring relative gravimeter. We calculated the residual Bouguer anomaly and identified three main zones with negative anomalies, ranging from −4 to −8 mGal, located southwest and west of South Sister, within an area that has been uplifting for the past two decades. After inversion, we obtain a 3D density model of the subsurface and identify low-density bodies extending from the surface down to 3 km. We estimate a total of 15 km³ of crustal bodies with density close to 2 g/cm³ that could store up to ~5 km³ of water, forming an extensive hydrothermal system beneath the TSVC. We explore the possible combinations of melt compositions and temperatures that could create a bulk density close to our reference crustal density (2.5 g/cm³) using MELTS thermodynamic simulations. Our results indicate that a magmatic mush with as little as 15% partial melt of bulk rhyolitic composition or as much as 52%–57% partial melt of a bulk dacitic composition could be stored in a magmatic system under TSVC without generating a detectable gravity anomaly. Episodic magma injections at the base of the magmatic system, such as the 1998–2000 intrusion at ~6 km depth, would bring heat and gas to the hydrothermal system while maintaining a low melt fraction in the magmatic mush, as imaged at other Cascade volcanoes.
