Response of the tallest California building during the Mw7.1 July 5, 2019 Ridgecrest, California earthquake

The 73-story Wilshire Grand in downtown Los Angeles is the recently constructed tallest building in California. It is designed in conformance with performance-based design procedures. The lateral load resisting system of the building is designed with concrete core shear walls, three outriggers with buckling restrained braces (BRBs) located along the height and two three-story truss-belt structural systems. The building is equipped with a 36-channel accelerometric seismic monitoring array that recorded the recent Mw7.1 Ridgecrest earthquake of July 5, 2019, as well as the Mw6.4 July 4, 2019 Ridgecrest Earthquake. In this paper, only the Mw7.1 July 5, 2019 event is studied because of a larger response of the subject building during that earthquake. The earthquake records of July 5, 2019 are specifically studied to determine its dynamic characteristics and building specific behavior. The structure exhibits torsional behavior most likely due to abrupt asymmetrical changes in the thickness and size in-plan of the core shear wall system. Modal shapes, frequencies and critical damping percentages of the building are identified. The translational and torsional modes during the earthquake are not closely coupled with fundamental NS, EW and torsional frequencies (periods) of 0.16 (6.25), 0.27(3.70) and 0.42 (2.38) Hz (seconds). This does not lead to a beating effect even though there is an appearance of it in the displacement records. Due to the relatively low amplitude of shaking during the earthquake, the drift ratios are too small to cause any damage. It is expected that during stronger shaking levels likely to be caused by future events, these characteristics may change and the effect of BRB’s can be better assessed.
