Responses of a 64-story unique San Francisco, CA. building to four earthquakes and ambient motions

We analyze the ambient and earthquake responses of a 64-story, instrumented, concrete core shear wall building in San Francisco, Calif. equipped with tuned sloshing liquid dampers (TSDs) and buckling restraining braces (BRBs). In an earlier paper [1], only ambient data were used to identify dynamic characteristics. Recently, the 72-channel instrumental array of the building recorded the 24 August 2014 Mw6.0 South Napa and three other earthquakes – allowing comparison of the dynamic characteristics using ambient and earthquake data. Peak accelerations of ambient and the larger South Napa EQ responses at the basement are 0.12 and 5.2 cm/s/s, respectively – a factor of ~ 42 and, at the 61st level, are 0.30 and 16.8 cm/s/s, respectively –a factor of ~56. Fundamental frequencies determined from spectral ratios for the NS (~0.3Hz), EW (0.27Hz) and torsional accelerations for the earthquake response vary within an insignificant frequency band of ~ 0.02-0.03 Hz as compared to those determined from ambient data. At the level of shaking, BRBs or TSDs are not effective enough to alter dynamic characteristics (frequency or damping). Under future stronger (e.g. design level) shaking of the building, the nonlinearities caused by actions of TSDs and BRBs can substantially shift the dynamic characteristics of the building.
