Risk assessment of brine contamination to aquatic resources from energy development in glacial drift deposits: Williston Basin, USA

Contamination to aquatic resources from co-produced water (brine) associated with energy development has been documented in the northeastern portion of the Williston Basin; an area mantled by glacial drift. The presence and magnitude of brine contamination can be determined using the contamination index (CI) value from water samples. Recently, the U.S. Geological Survey published a section (~ 2.59 km²) level risk assessment of brine contamination to aquatic resources for Sheridan County, Montana, using oilfield and hydrogeological parameters.
