Status and trends of pelagic and benthic prey fish populations in Lake Michigan, 2022

Fall bottom trawl (fall BT) and lakewide acoustic (AC) surveys are conducted annually to generate indices of pelagic and benthic prey fish densities in Lake Michigan. The fall BT survey has been conducted each fall since 1973 using 12-m trawls at depths ranging from 9 to 110 m at fixed locations distributed across seven transects; this survey estimates densities of seven prey fish species [i.e., Alewife (Alosa pseudoharengus), Bloater (Coregonus hoyi), Rainbow Smelt (Osmerus mordax), Deepwater Sculpin (Myoxocephalus thompsonii), Slimy Sculpin (Cottus cognatus), Round Goby (Neogobius melanostomus), Ninespine Stickleback (Pungitius pungitius)] as well as age-0 Yellow Perch (Perca flavescens) and large (> 350 mm) Burbot (Lota lota). The AC survey has been conducted each late summer/early fall since 2004, and the 2022 survey consisted of 26 transects [570 km total (354 miles)] covering bottom depths ranging from 5 to 255 m and 37 midwater trawl tows above bottom depths ranging 5 to 232 m; this survey estimates densities of three prey fish species (i.e., Alewife, Bloater, and Rainbow Smelt). The data generated from these surveys are used to estimate various population parameters that are, in turn, used by state and tribal agencies in managing Lake Michigan fish stocks. In spring of 2022, an additional spring bottom trawl survey (spring BT) was implemented across six of the transects sampled in the fall and sites ranged in depth from 9 to 236 m. The goal of the spring BT was to explore seasonal differences in biomass density and distributions of key prey species, mostly notably Alewife.

Total prey fish biomass density from the spring BT was 2.1 kg/ha. For the AC survey, total biomass density of prey fish equaled 6.2 kg/ha, 37% higher than the long-term average (2004-2021) of 4.5 kg/ha and 0.43 kg/ha higher than the 2021 estimate. For the fall BT, total biomass density of prey fish equaled 8.7 kg/ha, the highest value since 2013 and 21% higher than average value from 20042021 (6.8 kg/ha). The 2022 fall BT biomass density was still well below the average over the entirety of the time series (1973-2021; 34.3 kg/ha). Over the period both surveys have been conducted (2004-2021), total biomass density has trended downward in the fall BT (despite a high 2022 estimate) and remained relatively stable in the AC survey.

Bloater was the dominant species (by biomass) among prey fishes in both the spring and fall BT, while the AC survey reported co-dominance of Bloater and Alewife. Mean biomass of yearling and older (YAO) Alewife was 0.38 kg/ha in the spring BT, 3.0 kg/ha in the AC survey, and 0.10 in the fall BT. Alewife were aggregated in deepwater habitats in the spring of 2022 (> 110 m). Since 2014, catchability of YAO Alewives for the fall BT has been substantially lower than the AC survey. Results of the 2022 spring BT do not suggest that catchability is substantially higher in the spring than the fall.

Comparing the acoustic estimate to previous years, YAO Alewife biomass was 40% higher than the average from 2004-2021. An age-7 fish was recorded for the first time since 2009. Despite the rare catches of older fish, the Alewife age distribution still appears truncated, with age-1 fish as the most represented age class in all three surveys. Numeric density of age-0 Alewife from the AC survey was 7 fish/ha in 2022, which is the third lowest in the time series and well below the longterm mean of 452 fish/ha. Biomass density of large (≥120 mm) Bloater was 2.7 kg/ha in the AC survey and 4.4 kg/ha in the fall BT - each at least an order of magnitude lower than what was estimated by the fall BT between 1981 and 1998. Following a record high year in 2021 (1,037 fish/ha), the numeric density of small (<120 mm) Bloater was only 15 fish/ha in the AC survey.

Meanwhile, small Bloater density estimated in the fall BT was 261 fish/ha, the highest value since 1990 and likely partially reflective of a large 2021 year-class. Biomass density of large Rainbow Smelt (≥90 mm) was 0.29 kg/ha in the AC survey and 0.12 kg/ha in the fall BT survey, continuing the trend of low Rainbow Smelt biomass that has been observed since 2001. Numeric density of small (<90 mm) Rainbow Smelt was 21 fish/ha in the AC survey and 2.7 fish/ha in the fall BT, indicating a weak year-class. All four prey fish species sampled only by the fall BT indicated below average biomass densities. Deepwater Sculpin biomass density was estimated at 0.41 kg/ha, which makes 12 of the past 13 years when biomass was <1 kg/ha. Slimy Sculpin was estimated at 0.10 kg/ha, the highest estimate since 2016 but still only 25% of the long-term average. Round Goby was estimated at 1.3 kg/ha, above the average biomass of 0.82 kg/ha since 2008 but similar to intermittent high values observed throughout the dataset. Ninespine Stickleback density was 1.5 fish/ha. Burbot biomass remained near record low levels, and no age-0 Yellow Perch were caught, indicating a weak Yellow Perch year-class in 2022.
