Storm runoff as related to urbanization in the Portland, Oregon-Vancouver, Washington Area

January 1, 1980

A series of equations was developed to provide a better method of determining flood frequencies in the Portland-Vancouver urban area than is now available. The resulting regression equations can be used to compute peak discharge and storm runoff with a standard error of estimate of approximately 30 percent. Basins used to define the regression equations ranged in size from 0.2 to 26 square miles. Those physical basin parameters that proved to be significant are: drainage area, effective impervious area, storage, rainfall intensity, basin slope, and soil infiltration. The equations indicate that total urbanization of an undeveloped basin can increase peak discharge as much as 3? times and almost double the volume of storm runoff.

Impervious area, as delineated by mapping techniques, proved to be an inadequate physical parameter for use in the regression equations because builders and planners have devised many methods of routing storm runoff from impervious areas to the main channel (in effect, speeding up or slowing down the response to the storm). In some parts of the study area, storm runoff was diverted into dry wells and never entered the main channel. To define the effect of this rerouting, the digital model was used to find an effective impervious area that would 'best fit' the rainfall-runoff data. Field estimates to verify the effectiveness of the impervious area for two of the basins showed that optimizations were within 20 percent of those shown by the digital model.

Users of these data who may find the effective impervious area a difficult, expensive, and time-consuming parameter to obtain have an alternative. The combination of land-use type I (parks, forests, and vacant lots) and Type II (agriculture) proved to be an excellent inverse indicator of impervious area. Land-use types I and II, coupled with the street-gutter density, an indication of effective routing, provide the user with alternative indices of urbanization.

Publication Year 1980
Title Storm runoff as related to urbanization in the Portland, Oregon-Vancouver, Washington Area
DOI 10.3133/wri80689
Authors Antonius Laenen
Publication Type Report
Publication Subtype USGS Numbered Series
Series Title Water-Resources Investigations Report
Series Number 80-689
Index ID wri80689
Record Source USGS Publications Warehouse
USGS Organization Oregon Water Science Center
