Water-quality trends and constituent-transport analysis for selected sampling sites in the Milltown Reservoir/Clark Fork River Superfund Site in the upper Clark Fork Basin, Montana, water years 1996–2015

July 20, 2016

During the extended history of mining in the upper Clark Fork Basin in Montana, large amounts of waste materials enriched with metallic contaminants (cadmium, copper, lead, and zinc) and the metalloid trace element arsenic were generated from mining operations near Butte and milling and smelting operations near Anaconda. Extensive deposition of mining wastes in the Silver Bow Creek and Clark Fork channels and flood plains had substantial effects on water quality. Federal Superfund remediation activities in the upper Clark Fork Basin began in 1983 and have included substantial remediation near Butte and removal of the former Milltown Dam near Missoula. To aid in evaluating the effects of remediation activities on water quality, the U.S. Geological Survey began collecting streamflow and water-quality data in the upper Clark Fork Basin in the 1980s.

Trend analysis was done on specific conductance, selected trace elements (arsenic, copper, and zinc), and suspended sediment for seven sampling sites in the Milltown Reservoir/Clark Fork River Superfund Site for water years 1996–2015. The most upstream site included in trend analysis is Silver Bow Creek at Warm Springs, Montana (sampling site 8), and the most downstream site is Clark Fork above Missoula, Montana (sampling site 22), which is just downstream from the former Milltown Dam. Water year is the 12-month period from October 1 through September 30 and is designated by the year in which it ends. Trend analysis was done by using a joint time-series model for concentration and streamflow. To provide temporal resolution of changes in water quality, trend analysis was conducted for four sequential 5-year periods: period 1 (water years 1996–2000), period 2 (water years 2001–5), period 3 (water years 2006–10), and period 4 (water years 2011–15). Because of the substantial effect of the intentional breach of Milltown Dam on March 28, 2008, period 3 was subdivided into period 3A (October 1, 2005–March 27, 2008) and period 3B (March 28, 2008–September 30, 2010) for the Clark Fork above Missoula (sampling site 22). Trend results were considered statistically significant when the statistical probability level was less than 0.01.

In conjunction with the trend analysis, estimated normalized constituent loads (hereinafter referred to as “loads”) were calculated and presented within the framework of a constituent-transport analysis to assess the temporal trends in flow-adjusted concentrations (FACs) in the context of sources and transport. The transport analysis allows assessment of temporal changes in relative contributions from upstream source areas to loads transported past each reach outflow.

Trend results indicate that FACs of unfiltered-recoverable copper decreased at the sampling sites from the start of period 1 through the end of period 4; the decreases ranged from large for one sampling site (Silver Bow Creek at Warm Springs [sampling site 8]) to moderate for two sampling sites (Clark Fork near Galen, Montana [sampling site 11] and Clark Fork above Missoula [sampling site 22]) to small for four sampling sites (Clark Fork at Deer Lodge, Montana [sampling site 14], Clark Fork at Goldcreek, Montana [sampling site 16], Clark Fork near Drummond, Montana [sampling site 18], and Clark Fork at Turah Bridge near Bonner, Montana [sampling site 20]). For period 4 (water years 2011–15), the most notable changes indicated for the Milltown Reservoir/Clark Fork River Superfund Site were statistically significant decreases in FACs and loads of unfiltered-recoverable copper for sampling sites 8 and 22. The period 4 changes in FACs of unfiltered-recoverable copper for all other sampling sites were not statistically significant.

Trend results indicate that FACs of unfiltered-recoverable arsenic decreased at the sampling sites from period 1 through period 4 (water years 1996–2015); the decreases ranged from minor (sampling sites 8–20) to small (sampling site 22). For period 4 (water years 2011–15), the most notable changes indicated for the Milltown Reservoir/Clark Fork River Superfund Site were statistically significant decreases in FACs and loads of unfiltered-recoverable arsenic for sampling site 8 and near statistically significant decreases for sampling site 22. The period 4 changes in FACs of unfiltered-recoverable arsenic for all other sampling sites were not statistically significant.

Trend results indicate that FACs of suspended sediment decreased at the sampling sites from period 1 through period 4 (water years 1996–2015); the decreases ranged from moderate (sampling site 8) to small (sampling sites 11–22). For period 4 (water years 2011–15), the changes in FACs of suspended sediment were not statistically significant for any sampling sites.

The reach of the Clark Fork from Galen to Deer Lodge is a large source of metallic contaminants and suspended sediment, which strongly affects downstream transport of those constituents. Mobilization of copper and suspended sediment from flood-plain tailings and the streambed of the Clark Fork and its tributaries within the reach results in a contribution of those constituents that is proportionally much larger than the contribution of streamflow from within the reach. Within the reach from Galen to Deer Lodge, unfiltered-recoverable copper loads increased by a factor of about 4 and suspended-sediment loads increased by a factor of about 5, whereas streamflow increased by a factor of slightly less than 2. For period 4 (water years 2011–15), unfiltered-recoverable copper and suspended-sediment loads sourced from within the reach accounted for about 41 and 14 percent, respectively, of the loads at Clark Fork above Missoula (sampling site 22), whereas streamflow sourced from within the reach accounted for about 4 percent of the streamflow at sampling site 22. During water years 1996–2015, decreases in FACs and loads of unfiltered-recoverable copper and suspended sediment for the reach generally were proportionally smaller than for most other reaches.

Unfiltered-recoverable copper loads sourced within the reaches of the Clark Fork between Deer Lodge and Turah Bridge near Bonner (just upstream from the former Milltown Dam) were proportionally smaller than contributions of streamflow sourced from within the reaches; these reaches contributed proportionally much less to copper loading in the Clark Fork than the reach between Galen and Deer Lodge. Although substantial decreases in FACs and loads of unfiltered-recoverable copper and suspended sediment were indicated for Silver Bow Creek at Warm Springs (sampling site 8), those substantial decreases were not translated to downstream reaches between Deer Lodge and Turah Bridge near Bonner. The effect of the reach of the Clark Fork from Galen to Deer Lodge as a large source of copper and suspended sediment, in combination with little temporal change in those constituents for the reach, contributes to this pattern.

With the removal of the former Milltown Dam in 2008, substantial amounts of contaminated sediments that remained in the Clark Fork channel and flood plain in reach 9 (downstream from Turah Bridge near Bonner) became more available for mobilization and transport than before the dam removal. After the removal of the former Milltown Dam, the Clark Fork above Missoula (sampling site 22) had statistically significant decreases in FACs of unfiltered-recoverable copper in period 3B (March 28, 2008, through water year 2010) that continued in period 4 (water years 2011–15). Also, decreases in FACs of unfiltered-recoverable arsenic and suspended sediment were indicated for period 4 at this site. The decrease in FACs of unfiltered-recoverable copper for sampling site 22 during period 4 was proportionally much larger than the decrease for the Clark Fork at Turah Bridge near Bonner (sampling site 20). Net mobilization of unfiltered-recoverable copper and arsenic from sources within reach 9 are smaller for period 4 than for period 1 when the former Milltown Dam was in place, providing evidence that contaminant source materials have been substantially reduced in reach 9.

Publication Year 2016
Title Water-quality trends and constituent-transport analysis for selected sampling sites in the Milltown Reservoir/Clark Fork River Superfund Site in the upper Clark Fork Basin, Montana, water years 1996–2015
DOI 10.3133/sir20165100
Authors Steven K. Sando, Aldo V. Vecchia
Publication Type Report
Publication Subtype USGS Numbered Series
Series Title Scientific Investigations Report
Series Number 2016-5100
Index ID sir20165100
Record Source USGS Publications Warehouse
USGS Organization WY-MT Water Science Center
