World Map Showing Surface and Subsurface Distribution, and Lithologic Character of Middle and Late Neoproterozoic Rocks

July 31, 2007


The map was prepared to outline the basic information on where Neoproterozoic rocks are present in the World, and of the lithologic character of these rocks. The information provides a better understanding of major Neoproterozoic tectonic subdivisions useful in paleogeographic and plate tectonic reconstructions.

The time frame of the map is within the middle and late Neoproterozoic from approximately 870 to 540 Ma and is after widespread Mesoproterozoic Grenville-age collisional events that are considered to have formed the hypothetical supercontinent of Rodinia. Much of the time represented by the map is interpreted to be during the fragmentation of Rodinia.

The recognition of Neoproterozoic rocks is commonly difficult because of limited isotopic or paloeontological dating. Thus, some rocks shown on the map could be older or younger than the age indicated. However, at the scale of the map the the problem may be minor. Enough information seems to be available to indicate the general age of the rocks. Many of the successions contain diamictite deposits considered to be glaciogenic and dated as middle or late Neoproterozoic. These deposits thus show a rough correlation of middle and late Neoproterozoic rocks of the world. The map is a Richardson map projection, except for Antarctica which is a polar projection.

The map was prepared from about 650 references, shown in the text linked below under 'Sources of Information', used to outline distribution patterns, determine rock types, and provide information on the regional and local geologic framework of the rocks. The focus of the references is on the geologic information needed to prepare the map. Other information, such as plate tectonic reconstructions or paleomagnetic studies is generally not included.

The 'Sources of Information' lists references alphabetically for each of 14 regions. In brackets is a code for each area. These codes provide help in locating the specific regions in the references.

Publication Year 2007
Title World Map Showing Surface and Subsurface Distribution, and Lithologic Character of Middle and Late Neoproterozoic Rocks
DOI 10.3133/ofr20071087
Authors John H. Stewart
Publication Type Report
Publication Subtype USGS Numbered Series
Series Title Open-File Report
Series Number 2007-1087
Index ID ofr20071087
Record Source USGS Publications Warehouse
USGS Organization Western Mineral Resources
