High-resolution geophysical and geological data collected in Little Egg Inlet and offshore the southern end of Long Beach Island, NJ, during USGS Field Activities 2018-001-FA and 2018-049-FA
The natural resiliency of the New Jersey barrier island system, and the efficacy of management efforts to reduce vulnerability, depends on the ability of the system to recover and maintain equilibrium in response to storms and persistent coastal change. This resiliency is largely dependent on the availability of sand in the beach system. In an effort to better understand the system's sand budget and processes in which this system evolves, high-resolution geophysical mapping of the sea floor in Little Egg Inlet and along the southern end of Long Beach Island near Beach Haven, New Jersey was conducted from May 31 to June 10, 2018, followed by a sea floor sampling survey conducted from October 22 to 23, 2018, as part of a collaborative effort between the U.S. Geological Survey and Stockton University. Multibeam echo sounder bathymetry and backscatter data were collected along 741 kilometers of tracklines (approximately 200 square kilometers) of the coastal sea floor to regionally define its depth and morphology, as well as the type and distribution of sea-floor sediments. Six hundred ninety-two kilometers of seismic-reflection profile data were also collected to define the thickness and structure of sediment deposits in the inlet and offshore. These new data will help inform future management decisions that affect the natural and recreational resources of the area around and offshore of Little Egg Inlet. These mapping surveys provide high-quality data needed to build scientific knowledge of the evolution and behavior of the New Jersey barrier island system.
Citation Information
| Publication Year | 2021 |
|---|---|
| Title | High-resolution geophysical and geological data collected in Little Egg Inlet and offshore the southern end of Long Beach Island, NJ, during USGS Field Activities 2018-001-FA and 2018-049-FA |
| DOI | 10.5066/P9C3J33K |
| Authors | Seth Ackerman, Walter Barnhardt, Charles R Worley, Alexander R Nichols, Wayne E Baldwin, Steve Evert |
| Product Type | Data Release |
| Record Source | USGS Digital Object Identifier Catalog |
| USGS Organization | Woods Hole Coastal and Marine Science Center |
